Class implementing 3D and 1D Real-To-Complex and Complex-To-Real transforms using FFTW interface. More...

#include <FftwComplexMatrix.h>

Inheritance diagram for FftwComplexMatrix:

Collaboration diagram for FftwComplexMatrix:

[legend]

Public Member Functions
	FftwComplexMatrix ()=delete
	Default constructor not allowed for public.

	FftwComplexMatrix (const DimensionSizes &dimensionSizes)
	Constructor, inherited from ComplexMatrix. More...

	FftwComplexMatrix (const FftwComplexMatrix &src)=delete
	Copy constructor not allowed for public.

virtual	~FftwComplexMatrix ()
	Destructor. More...

FftwComplexMatrix &	operator= (const FftwComplexMatrix &src)
	Operator = not allowed for public.

void	createR2CFftPlan3D (RealMatrix &inMatrix)
	Create FFTW plan for 3D Real-to-Complex. More...

void	createC2RFftPlan3D (RealMatrix &outMatrix)
	Create FFTW plan for 3D Complex-to-Real. More...

void	createR2CFftPlan1DX (RealMatrix &inMatrix)
	Create an FFTW plan for 1D Real-to-Complex in the x dimension. More...

void	createR2CFftPlan1DY (RealMatrix &inMatrix)
	Create an FFTW plan for 1D Real-to-Complex in the y dimension. More...

void	createR2CFftPlan1DZ (RealMatrix &inMatrix)
	Create an FFTW plan for 1D Real-to-Complex in the z dimension. More...

void	createC2RFftPlan1DX (RealMatrix &outMatrix)
	Create FFTW plan for Complex-to-Real in the x dimension. More...

void	createC2RFftPlan1DY (RealMatrix &outMatrix)
	Create FFTW plan for Complex-to-Real in the y dimension. More...

void	createC2RFftPlan1DZ (RealMatrix &outMatrix)
	Create FFTW plan for Complex-to-Real in the z dimension. More...

void	computeR2CFft3D (RealMatrix &inMatrix)
	Compute forward out-of-place 3D Real-to-Complex FFT. More...

void	computeC2RFft3D (RealMatrix &outMatrix)
	Compute forward out-of-place 3D Complex-to-Real FFT. More...

void	computeR2CFft1DX (RealMatrix &inMatrix)
	Compute 1D out-of-place Real-to-Complex FFT in the x dimension. More...

void	computeR2CFft1DY (RealMatrix &inMatrix)
	Compute 1D out-of-place Real-to-Complex FFT in the y dimension. More...

void	computeR2CFft1DZ (RealMatrix &inMatrix)
	Compute 1D out-of-place Real-to-Complex FFT in the z dimension. More...

void	computeC2RFft1DX (RealMatrix &outMatrix)
	Compute 1D out-of-place Complex-to-Real FFT in the x dimension. More...

void	computeC2RFft1DY (RealMatrix &outMatrix)
	Compute 1D out-of-place Complex-to-Real FFT in the y dimension. More...

void	computeC2RFft1DZ (RealMatrix &outMatrix)
	Compute 1D out-of-place Complex-to-Real FFT in the z dimension. More...

Public Member Functions inherited from ComplexMatrix
	ComplexMatrix ()=delete
	Default constructor not allowed.

	ComplexMatrix (const DimensionSizes &dimensionSizes)
	Constructor. More...

	ComplexMatrix (const ComplexMatrix &)=delete
	Copy constructor not allowed.

virtual	~ComplexMatrix ()
	Destructor. More...

ComplexMatrix &	operator= (const ComplexMatrix &)
	Operator= is not allowed.

virtual void	readData (Hdf5File &file, MatrixName &matrixName)
	Read matrix from HDF5 file. More...

virtual void	writeData (Hdf5File &file, MatrixName &matrixName, const size_t compressionLevel)
	Write data into HDF5 file. More...

virtual FloatComplex *	getComplexData ()
	Get raw complex data out of the class (for direct kernel access). More...

virtual const FloatComplex *	getComplexData () const
	Get raw complex data out of the class (for direct kernel access). More...

FloatComplex &	operator[] (const size_t &index)
	Operator []. More...

const FloatComplex &	operator[] (const size_t &index) const
	Operator [], constant version. More...

FloatComplex &	GetElementFrom3D (const size_t x, const size_t y, const size_t z)
	Get element from 3D matrix. More...

const FloatComplex &	GetElementFrom3D (const size_t x, const size_t y, const size_t z) const
	Get element from 3D matrix, constant version. More...

Public Member Functions inherited from BaseFloatMatrix
	BaseFloatMatrix ()
	Default constructor. More...

	BaseFloatMatrix (const BaseFloatMatrix &)=delete
	Copy constructor is not allowed.

virtual	~BaseFloatMatrix ()
	Destructor.

BaseFloatMatrix &	operator= (const BaseFloatMatrix &)=delete
	operator= is not allowed.

virtual const DimensionSizes &	getDimensionSizes () const
	Get dimension sizes of the matrix. More...

virtual size_t	size () const
	Size of the matrix. More...

virtual size_t	capacity () const
	The capacity of the matrix (this may differ from size due to padding, etc.). More...

virtual void	copyData (const BaseFloatMatrix &src)
	Copy data from other matrix with the same size. More...

virtual void	zeroMatrix ()
	Zero all elements of the matrix (NUMA first touch). More...

virtual void	scalarDividedBy (const float scalar)
	Calculate matrix = scalar / matrix. More...

virtual float *	getData ()
	Get raw data out of the class (for direct kernel access). More...

virtual const float *	getData () const
	Get raw data out of the class (for direct kernel access), const version. More...

Public Member Functions inherited from BaseMatrix
	BaseMatrix ()
	Default constructor.

	BaseMatrix (const BaseMatrix &)=delete
	Copy constructor is not allowed.

virtual	~BaseMatrix ()
	Destructor.

BaseMatrix &	operator= (const BaseMatrix &)=delete
	Operator= is not allowed.

Static Public Member Functions
static void	exportWisdom ()
	Export wisdom to the file. More...

static void	importWisdom ()
	Import wisdom from the file. More...

static void	deleteStoredWisdom ()
	Destroy wisdom in the file (delete it). More...

Protected Member Functions
virtual void	allocateMemory ()
	Allocate memory for the FFTW matrix. More...

virtual void	freeMemory ()
	Free memory of the FFTW matrix. More...

Static Protected Member Functions
static std::string	getWisdomFileName ()

Protected Attributes
fftwf_plan	mR2CFftPlan3D
	FFTW plan for the 3D Real-to-Complex transform.

fftwf_plan	mC2RFftPlan3D
	FFTW plan for the 3D Complex-to-Real transform.

fftwf_plan	mR2CFftPlan1DX
	FFTW plan for the 1D Real-to-Complex transform in the x dimension.

fftwf_plan	mR2CFftPlan1DY
	FFTW plan for the 3D Real-to-Complex transform in the y dimension.

fftwf_plan	mR2CFftPlan1DZ
	FFTW plan for the 3D Real-to-Complex transform in the z dimension.

fftwf_plan	mC2RFftPlan1DX
	FFTW plan for the 3D Complex-to-Real transform in the x dimension.

fftwf_plan	mC2RFftPlan1DY
	FFTW plan for the 3D Complex-to-Real transform in the y dimension.

fftwf_plan	mC2RFftPlan1DZ
	FFTW plan for the 3Z Complex-to-Real transform in the z dimension.

Protected Attributes inherited from BaseFloatMatrix
size_t	mSize
	Total number of used elements.

size_t	mCapacity
	Total number of allocated elements (in terms of floats).

DimensionSizes	mDimensionSizes
	Dimension sizes.

size_t	mRowSize
	Size of a 1D row in X dimension.

size_t	mSlabSize
	Size of a XY slab.

float *	mData
	Raw matrix data.

Static Protected Attributes
static const unsigned	kFftMeasureFlag = FFTW_MEASURE
	FFTW plan flag.

static const std::string	kFftWisdomFileExtension = "FFTW_Wisdom"
	The file extension for FFTW wisdom.

Detailed Description

Class implementing 3D and 1D Real-To-Complex and Complex-To-Real transforms using FFTW interface.

Definition at line 46 of file FftwComplexMatrix.h.

Constructor & Destructor Documentation

◆ FftwComplexMatrix()

FftwComplexMatrix::FftwComplexMatrix ( const DimensionSizes & dimensionSizes )

Parameters

[in] dimensionSizes - Dimension sizes of the matrix.

Constructor.

Definition at line 54 of file FftwComplexMatrix.cpp.

◆ ~FftwComplexMatrix()

FftwComplexMatrix::~FftwComplexMatrix ( )

virtual

Destructor.

Definition at line 66 of file FftwComplexMatrix.cpp.

Member Function Documentation

◆ allocateMemory()

void FftwComplexMatrix::allocateMemory ( )

protectedvirtual

Allocate Memory using fftwf_malloc function to ensure correct alignment.

Reimplemented from BaseFloatMatrix.

Definition at line 785 of file FftwComplexMatrix.cpp.

◆ computeC2RFft1DX()

void FftwComplexMatrix::computeC2RFft1DX ( RealMatrix & outMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build! The FFTW version processes the whole matrix at one while the MKL slab by slab.

Parameters

[out] outMatrix - Output matrix

Exceptions

std::runtime_error - If the plan is not valid.

Compute 1D out-of-place Complex-to-Real FFT in the x dimension.

Definition at line 644 of file FftwComplexMatrix.cpp.

◆ computeC2RFft1DY()

void FftwComplexMatrix::computeC2RFft1DY ( RealMatrix & outMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build! The FFTW version processes the whole matrix at one while the MKL slab by slab.

Parameters

[out] outMatrix - Output matrix

Exceptions

std::runtime_error - If the plan is not valid.

Compute 1D out-of-place Complex-to-Real FFT in the y dimension.

Definition at line 676 of file FftwComplexMatrix.cpp.

◆ computeC2RFft1DZ()

void FftwComplexMatrix::computeC2RFft1DZ ( RealMatrix & outMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build! The FFTW version processes the whole matrix at one while the MKL slab by slab.

Parameters

[out] outMatrix Output matrix

Exceptions

std::runtime_error - If the plan is not valid.

Compute 1D out-of-place Complex-to-Real FFT in the Z dimension

Definition at line 708 of file FftwComplexMatrix.cpp.

◆ computeC2RFft3D()

void FftwComplexMatrix::computeC2RFft3D ( RealMatrix & outMatrix )

Parameters

[out] outMatrix - Output of the inverse FFT.

Exceptions

std::runtime_error - If the plan is not valid.

Compute inverse out-of-place 3D Complex to Real FFT.

Definition at line 532 of file FftwComplexMatrix.cpp.

◆ computeR2CFft1DX()

void FftwComplexMatrix::computeR2CFft1DX ( RealMatrix & inMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build! The FFTW version processes the whole matrix at one while the MKL slab by slab.

Parameters

[in] inMatrix - Input matrix

Exceptions

std::runtime_error - If the plan is not valid.

Compute 1D out-of-place Real-to-Complex FFT in the x dimension.

Definition at line 548 of file FftwComplexMatrix.cpp.

◆ computeR2CFft1DY()

void FftwComplexMatrix::computeR2CFft1DY ( RealMatrix & inMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build! The FFTW version processes the whole matrix at one while the MKL slab by slab.

Parameters

[in] inMatrix - Input matrix

Exceptions

std::runtime_error - If the plan is not valid.

Compute 1D out-of-place Real-to-Complex FFT in the Y dimension.

Definition at line 580 of file FftwComplexMatrix.cpp.

◆ computeR2CFft1DZ()

void FftwComplexMatrix::computeR2CFft1DZ ( RealMatrix & inMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build! The FFTW version processes the whole matrix at one while the MKL slab by slab.

Parameters

[in] inMatrix - Input matrix

Exceptions

std::runtime_error - If the plan is not valid.

Compute 1D out-of-place Real-to-Complex FFT in the z dimension.

Definition at line 612 of file FftwComplexMatrix.cpp.

◆ computeR2CFft3D()

void FftwComplexMatrix::computeR2CFft3D ( RealMatrix & inMatrix )

Parameters

[in] inMatrix - Input data for the forward FFT.

Exceptions

std::runtime_error - If the plan is not valid.

Computer forward out-of place 3D Real-to-Complex FFT.

Definition at line 516 of file FftwComplexMatrix.cpp.

◆ createC2RFftPlan1DX()

void FftwComplexMatrix::createC2RFftPlan1DX ( RealMatrix & outMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build!
The FFTW version processes the whole matrix at one while the MKL slab by slab.

Parameters

[in,out] outMatrix - RealMatrix of which to create the plan.

Exceptions

std::runtime_error - If the plan can't be created.

Warning: Unless FFTW_ESTIMATE flag is specified, the content of the outMatrix is destroyed!

Create FFTW plan for Complex-to-Real in the x dimension.

Definition at line 328 of file FftwComplexMatrix.cpp.

◆ createC2RFftPlan1DY()

void FftwComplexMatrix::createC2RFftPlan1DY ( RealMatrix & outMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build!
The FFTW version processes the whole matrix at one while the MKL slab by slab.

Parameters

[in,out] outMatrix - RealMatrix of which to create the plan.

Exceptions

std::runtime_error - If the plan can't be created.

Warning: Unless FFTW_ESTIMATE flag is specified, the content of the outMatrix is destroyed!

Create FFTW plan for Complex-to-Real in the y dimension.

Definition at line 391 of file FftwComplexMatrix.cpp.

◆ createC2RFftPlan1DZ()

void FftwComplexMatrix::createC2RFftPlan1DZ ( RealMatrix & outMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build!
The FFTW version processes the whole matrix at one while the MKL slab by slab.

Parameters

[in,out] outMatrix - RealMatrix of which to create the plan.

Exceptions

std::runtime_error - If the plan can't be created.

Warning: Unless FFTW_ESTIMATE flag is specified, the content of the outMatrix is destroyed!

Create FFTW plan for Complex-to-Real in the z dimension.

Definition at line 454 of file FftwComplexMatrix.cpp.

◆ createC2RFftPlan3D()

void FftwComplexMatrix::createC2RFftPlan3D ( RealMatrix & outMatrix )

Parameters

[in] outMatrix - Output matrix serving as scratch place for planning.

Exceptions

std::runtime_error - If the plan can't be created.

Warning: Unless FFTW_ESTIMATE flag is specified, the content of the outMatrix is destroyed!

Create an FFTW plan for 3D Complex-to-Real.

Definition at line 120 of file FftwComplexMatrix.cpp.

◆ createR2CFftPlan1DX()

void FftwComplexMatrix::createR2CFftPlan1DX ( RealMatrix & inMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build!
The FFTW version processes the whole matrix at one while the MKL slab by slab.

Parameters

[in,out] inMatrix - RealMatrix of which to create the plan.

Exceptions

std::runtime_error - If the plan can't be created.

Warning: Unless FFTW_ESTIMATE flag is specified, the content of the inMatrix is destroyed!

Create an FFTW plan for 1D Real-to-Complex in the x dimension.

Definition at line 139 of file FftwComplexMatrix.cpp.

◆ createR2CFftPlan1DY()

void FftwComplexMatrix::createR2CFftPlan1DY ( RealMatrix & inMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build!
The FFTW version processes the whole matrix at one while the MKL slab by slab

Parameters

[in,out] inMatrix - RealMatrix of which to create the plan.

Exceptions

std::runtime_error - If the plan can't be created.

Warning: Unless FFTW_ESTIMATE flag is specified, the content of the inMatrix is destroyed!; The FFTW matrix must be able to store 2 * (nx * (ny /2 + 1) * nz) elements - possibly more than reduced dims!

Create an FFTW plan for 1D Real-to-Complex in the y dimension.

Definition at line 203 of file FftwComplexMatrix.cpp.

◆ createR2CFftPlan1DZ()

void FftwComplexMatrix::createR2CFftPlan1DZ ( RealMatrix & inMatrix )

There are two versions of this routine for GCC+FFTW and ICPC + MKL, otherwise it will not build!
The FFTW version processes the whole matrix at one while the MKL slab by slab

Parameters

[in,out] inMatrix - RealMatrix of which to create the plan.

Exceptions

std::runtime_error - If the plan can't be created.

Warning: Unless FFTW_ESTIMATE flag is specified, the content of the inMatrix is destroyed!; The FFTW matrix must be able to store 2 * (nx * by * (nz / 2 + 1)) elements - possibly more than reduced dims!

Create an FFTW plan for 1D Real-to-Complex in the z dimension.

Definition at line 266 of file FftwComplexMatrix.cpp.

◆ createR2CFftPlan3D()

void FftwComplexMatrix::createR2CFftPlan3D ( RealMatrix & inMatrix )

Parameters

[in] inMatrix - Input matrix serving as scratch place for planning.

Exceptions

std::runtime_error - If the plan can't be created.

Warning: Unless FFTW_ESTIMATE flag is specified, the content of the inMatrix is destroyed!

Create an FFTW plan for 3D Real-to-Complex.

Definition at line 101 of file FftwComplexMatrix.cpp.

◆ deleteStoredWisdom()

void FftwComplexMatrix::deleteStoredWisdom ( )

static

Delete stored wisdom (delete the file).

Definition at line 771 of file FftwComplexMatrix.cpp.

◆ exportWisdom()

void FftwComplexMatrix::exportWisdom ( )

static

Warning: This routine is supported only while compiling with the GNU C++ compiler.

Export wisdom to the file.

Definition at line 740 of file FftwComplexMatrix.cpp.

◆ freeMemory()

void FftwComplexMatrix::freeMemory ( )

protectedvirtual

Free memory using fftwf_free.

Reimplemented from BaseFloatMatrix.

Definition at line 807 of file FftwComplexMatrix.cpp.

◆ getWisdomFileName()

std::string FftwComplexMatrix::getWisdomFileName ( )

staticprotected

Get Wisdom file name (derive it form the checkpoint filename).

Returns: the filename for wisdom.

Get Wisdom file name (derive it form the checkpoint filename).

Definition at line 817 of file FftwComplexMatrix.cpp.

◆ importWisdom()

void FftwComplexMatrix::importWisdom ( )

static

Warning: This routine is supported only while compiling with the GNU C++ compiler.

Import wisdom from the file.

Definition at line 755 of file FftwComplexMatrix.cpp.

The documentation for this class was generated from the following files:

MatrixClasses/FftwComplexMatrix.h
MatrixClasses/FftwComplexMatrix.cpp

Public Member Functions

Static Public Member Functions

Protected Member Functions

Static Protected Member Functions

Protected Attributes

Static Protected Attributes

Detailed Description

Constructor & Destructor Documentation

◆ FftwComplexMatrix()

◆ ~FftwComplexMatrix()

Member Function Documentation

◆ allocateMemory()

◆ computeC2RFft1DX()

◆ computeC2RFft1DY()

◆ computeC2RFft1DZ()

◆ computeC2RFft3D()

◆ computeR2CFft1DX()

◆ computeR2CFft1DY()

◆ computeR2CFft1DZ()

◆ computeR2CFft3D()

◆ createC2RFftPlan1DX()

◆ createC2RFftPlan1DY()

◆ createC2RFftPlan1DZ()

◆ createC2RFftPlan3D()

◆ createR2CFftPlan1DX()

◆ createR2CFftPlan1DY()

◆ createR2CFftPlan1DZ()

◆ createR2CFftPlan3D()

◆ deleteStoredWisdom()

◆ exportWisdom()

◆ freeMemory()

◆ getWisdomFileName()

◆ importWisdom()
