Class for HDF5 file header. More...

#include <Hdf5FileHeader.h>

Collaboration diagram for Hdf5FileHeader:

Public Types
enum	FileHeaderItems { FileHeaderItems::kCreatedBy = 0, FileHeaderItems::kCreationDate = 1, FileHeaderItems::kFileDescription = 2, FileHeaderItems::kMajorVersion = 3, FileHeaderItems::kMinorVersion = 4, FileHeaderItems::kFileType = 5, FileHeaderItems::kHostName = 6, FileHeaderItems::kTotalMemoryConsumption = 7, FileHeaderItems::kPeakMemoryConsumption = 8, FileHeaderItems::kTotalExecutionTime = 9, FileHeaderItems::kDataLoadTime = 10, FileHeaderItems::kPreProcessingTime = 11, FileHeaderItems::kSimulationTime = 12, FileHeaderItems::kPostProcessingTime = 13, FileHeaderItems::kNumberOfCores = 14 }
	List of all header items. More...

enum	FileType { FileType::kInput = 0, FileType::kOutput = 1, FileType::kCheckpoint = 2, FileType::kUnknown = 3 }
	HDF5 file type. More...

enum	FileVersion { FileVersion::kVersion10 = 0, FileVersion::kVersion11 = 1, FileVersion::kVersionUnknown = 2 }
	HDF5 file version. More...

Public Member Functions
	Hdf5FileHeader ()
	Constructor. More...

	Hdf5FileHeader (const Hdf5FileHeader &src)
	Copy constructor. More...

	~Hdf5FileHeader ()
	Destructor. More...

void	readHeaderFromInputFile (Hdf5File &inputFile)
	Read header from the input file. More...

void	readHeaderFromOutputFile (Hdf5File &outputFile)
	Read header from output file (necessary for checkpoint-restart). More...

void	readHeaderFromCheckpointFile (Hdf5File &checkpointFile)
	Read the file header form the checkpoint file. More...

void	writeHeaderToOutputFile (Hdf5File &outputFile)
	Write header into the output file. More...

void	writeHeaderToCheckpointFile (Hdf5File &checkpointFile)
	Write header to the output file (only a subset of all possible fields are written). More...

void	setCodeName (const std::string &codeName)
	Set code name. More...

void	setActualCreationTime ()
	Set creation time. More...

void	setMajorFileVersion ()
	Set major file version.

void	setMinorFileVersion ()
	Set minor file version.

FileVersion	getFileVersion ()
	Get file version as an enum. More...

bool	checkMajorFileVersion ()
	Check major file version. More...

bool	checkMinorFileVersion ()
	Check minor file version. More...

Hdf5FileHeader::FileType	getFileType ()
	Get File type. More...

void	setFileType (const Hdf5FileHeader::FileType fileType)
	Set File type. More...

void	setHostName ()
	Set host name. More...

void	setMemoryConsumption (const size_t totalMemory)
	Set memory consumption. More...

void	setExecutionTimes (const double totalTime, const double loadTime, const double preProcessingTime, const double simulationTime, const double postprocessingTime)
	Set execution times in file header. More...

void	getExecutionTimes (double &totalTime, double &loadTime, double &preProcessingTime, double &simulationTime, double &postprocessingTime)
	Get execution times stored in the output file header. More...

void	setNumberOfCores ()
	Set number of cores. More...

Static Public Member Functions
static std::string	getFileMajorVersion ()
	Get string representing of current Major version of the file. More...

static std::string	getFileMinorVersion ()
	Get string representing of current Minor version of the file. More...

Private Attributes
std::map< FileHeaderItems, std::string >	mHeaderValues
	map for the header values.

Static Private Attributes
static std::map< FileHeaderItems, std::string >	sHeaderNames
	map for the header names. More...

static const std::string	kFileTypesNames [] = {"input", "output", "checkpoint", "unknown"}
	String representation of different file types.

static const std::string	kMajorFileVersionsNames [] = {"1"}
	String representations of Major file versions.

static const std::string	kMinorFileVersionsNames [] = {"0","1"}
	String representations of Major file versions.

Detailed Description

This class manages all information that can be stored in the input output or checkpoint file header.

Definition at line 89 of file Hdf5FileHeader.h.

Member Enumeration Documentation

◆ FileHeaderItems

enum Hdf5FileHeader::FileHeaderItems

strong

List of all header items.

Todo:: In the future, we should add number of GPUs, peak GPU memory.

Enumerator
kCreatedBy	Code that created the file.
kCreationDate	When the file was created.
kFileDescription	Description of the file (e.g. simulation).
kMajorVersion	Major file version.
kMinorVersion	Minor file version.
kFileType	File type.
kHostName	Machines the code were executed on.
kTotalMemoryConsumption	Total amount of memory consumed by the code.
kPeakMemoryConsumption	Peak memory consumption (by process).
kTotalExecutionTime	Total execution time.
kDataLoadTime	Time to load data in.
kPreProcessingTime	Time to preprocess data.
kSimulationTime	Simulation time.
kPostProcessingTime	Time to postprocess data.
kNumberOfCores	Number of cores the simulation was executed.

Definition at line 99 of file Hdf5FileHeader.h.

◆ FileType

enum Hdf5FileHeader::FileType

strong

HDF5 file type.

Enumerator
kInput	Input file.
kOutput	Output file.
kCheckpoint	Checkpoint file.
kUnknown	Unknown file.

Definition at line 138 of file Hdf5FileHeader.h.

◆ FileVersion

enum Hdf5FileHeader::FileVersion

strong

HDF5 file version.

Enumerator
kVersion10	Version 1.0.
kVersion11	Version 1.1.
kVersionUnknown	Version unknown.

Definition at line 155 of file Hdf5FileHeader.h.

Constructor & Destructor Documentation

◆ Hdf5FileHeader() [1/2]

Hdf5FileHeader::Hdf5FileHeader ( )

Constructor.

Definition at line 97 of file Hdf5FileHeader.cpp.

◆ Hdf5FileHeader() [2/2]

Hdf5FileHeader::Hdf5FileHeader ( const Hdf5FileHeader & src )

Parameters

[in] src - Source object.

Copy constructor.

Definition at line 107 of file Hdf5FileHeader.cpp.

◆ ~Hdf5FileHeader()

Hdf5FileHeader::~Hdf5FileHeader ( )

Destructor.

Definition at line 117 of file Hdf5FileHeader.cpp.

Member Function Documentation

◆ checkMajorFileVersion()

bool Hdf5FileHeader::checkMajorFileVersion ( )

inline

Returns: true - If the file version is supported.

Definition at line 267 of file Hdf5FileHeader.h.

◆ checkMinorFileVersion()

bool Hdf5FileHeader::checkMinorFileVersion ( )

inline

Returns: true - If the file version is supported.

Definition at line 275 of file Hdf5FileHeader.h.

◆ getExecutionTimes()

void Hdf5FileHeader::getExecutionTimes	(	double &	totalTime,
		double &	loadTime,
		double &	preProcessingTime,
		double &	simulationTime,
		double &	postprocessingTime
	)

Parameters

[out]	totalTime	- Total time.
[out]	loadTime	- Time to load data.
[out]	preProcessingTime	- Preprocessing time.
[out]	simulationTime	- Simulation time.
[out]	postprocessingTime	- Post processing time.

Get execution times stored in the output file header.

Definition at line 406 of file Hdf5FileHeader.cpp.

◆ getFileMajorVersion()

static std::string Hdf5FileHeader::getFileMajorVersion ( )

inlinestatic

Returns: Current major file version.

Definition at line 233 of file Hdf5FileHeader.h.

◆ getFileMinorVersion()

static std::string Hdf5FileHeader::getFileMinorVersion ( )

inlinestatic

Returns: Current minor file version.

Definition at line 241 of file Hdf5FileHeader.h.

◆ getFileType()

Hdf5FileHeader::FileType Hdf5FileHeader::getFileType ( )

Returns: File type.

Get File type.

Definition at line 322 of file Hdf5FileHeader.cpp.

◆ getFileVersion()

Hdf5FileHeader::FileVersion Hdf5FileHeader::getFileVersion ( )

Returns: File version as an enum.

Get file version as an enum.

Definition at line 300 of file Hdf5FileHeader.cpp.

◆ readHeaderFromCheckpointFile()

void Hdf5FileHeader::readHeaderFromCheckpointFile ( Hdf5File & checkpointFile )

We need the header to verify the file version and type.

Parameters

[in,out] checkpointFile - Checkpoint file handle.

Exceptions

ios:failure - If error happens.

Read the file header form the checkpoint file.

Definition at line 192 of file Hdf5FileHeader.cpp.

◆ readHeaderFromInputFile()

void Hdf5FileHeader::readHeaderFromInputFile ( Hdf5File & inputFile )

Parameters

[in,out] inputFile - Input file handle.

Exceptions

ios:failure - If error happens.

Read header from the input file.

Definition at line 126 of file Hdf5FileHeader.cpp.

◆ readHeaderFromOutputFile()

void Hdf5FileHeader::readHeaderFromOutputFile ( Hdf5File & outputFile )

Read only execution times (the others are read from the input file, or calculated based on the very last leg of the simulation). This function is called only if checkpoint-restart is enabled.

Parameters

[in,out] outputFile - Output file handle.

Exceptions

ios:failure - If error happens.

Read header from output file (necessary for checkpoint-restart).

Definition at line 160 of file Hdf5FileHeader.cpp.

◆ setActualCreationTime()

void Hdf5FileHeader::setActualCreationTime ( )

Set actual date and time.

Definition at line 284 of file Hdf5FileHeader.cpp.

◆ setCodeName()

void Hdf5FileHeader::setCodeName ( const std::string & codeName )

inline

Parameters

[in] codeName - Code version.

Definition at line 221 of file Hdf5FileHeader.h.

◆ setExecutionTimes()

void Hdf5FileHeader::setExecutionTimes	(	const double	totalTime,
		const double	loadTime,
		const double	preProcessingTime,
		const double	simulationTime,
		const double	postprocessingTime
	)

Parameters

[in]	totalTime	- Total time.
[in]	loadTime	- Time to load data.
[in]	preProcessingTime	- Preprocessing time.
[in]	simulationTime	- Simulation time.
[in]	postprocessingTime	- Post processing time.

Set execution times in file header.

Definition at line 389 of file Hdf5FileHeader.cpp.

◆ setFileType()

void Hdf5FileHeader::setFileType ( const Hdf5FileHeader::FileType fileType )

Parameters

[in] fileType - File type.

Set File type.

Definition at line 340 of file Hdf5FileHeader.cpp.

◆ setHostName()

void Hdf5FileHeader::setHostName ( )

Set Host name.

Definition at line 349 of file Hdf5FileHeader.cpp.

◆ setMemoryConsumption()

void Hdf5FileHeader::setMemoryConsumption ( const size_t totalMemory )

Parameters

[in] totalMemory - Total memory consumption.

Set memory consumption.

Definition at line 375 of file Hdf5FileHeader.cpp.

◆ setNumberOfCores()

void Hdf5FileHeader::setNumberOfCores ( )

Set Number of cores.

Definition at line 424 of file Hdf5FileHeader.cpp.

◆ writeHeaderToCheckpointFile()

void Hdf5FileHeader::writeHeaderToCheckpointFile ( Hdf5File & checkpointFile )

Parameters

[in,out] checkpointFile - Checkpoint file handle.

Exceptions

ios:failure - If error happens.

Write header to the output file (only a subset of all possible fields are written).

Definition at line 241 of file Hdf5FileHeader.cpp.

◆ writeHeaderToOutputFile()

void Hdf5FileHeader::writeHeaderToOutputFile ( Hdf5File & outputFile )

Parameters

[in,out] outputFile - Output file handle.

Exceptions

ios:failure - If error happens.

Write header into the output file.

Definition at line 225 of file Hdf5FileHeader.cpp.

Member Data Documentation

◆ sHeaderNames

std::map< Hdf5FileHeader::FileHeaderItems, std::string > Hdf5FileHeader::sHeaderNames

staticprivate

Initial value:

{
  {Hdf5FileHeader::FileHeaderItems::kCreatedBy             , "created_by"},
  {Hdf5FileHeader::FileHeaderItems::kCreationDate          , "creation_date"},
  {Hdf5FileHeader::FileHeaderItems::kFileDescription       , "file_description"},
  {Hdf5FileHeader::FileHeaderItems::kMajorVersion          , "major_version"},
  {Hdf5FileHeader::FileHeaderItems::kMinorVersion          , "minor_version"},
  {Hdf5FileHeader::FileHeaderItems::kFileType              , "file_type"},
  {Hdf5FileHeader::FileHeaderItems::kHostName              , "host_names"},
  {Hdf5FileHeader::FileHeaderItems::kNumberOfCores         , "number_of_cpu_cores"},
  {Hdf5FileHeader::FileHeaderItems::kTotalMemoryConsumption, "total_memory_in_use"},
  {Hdf5FileHeader::FileHeaderItems::kPeakMemoryConsumption , "peak_core_memory_in_use"},
  {Hdf5FileHeader::FileHeaderItems::kTotalExecutionTime    , "total_execution_time"},
  {Hdf5FileHeader::FileHeaderItems::kDataLoadTime          , "data_loading_phase_execution_time"},
  {Hdf5FileHeader::FileHeaderItems::kPreProcessingTime     , "pre-processing_phase_execution_time"},
  {Hdf5FileHeader::FileHeaderItems::kSimulationTime        , "simulation_phase_execution_time"},
  {Hdf5FileHeader::FileHeaderItems::kPostProcessingTime    , "post-processing_phase_execution_time"}
}

Initialisation of static map with header attribute names.

Definition at line 335 of file Hdf5FileHeader.h.

The documentation for this class was generated from the following files:

Hdf5/Hdf5FileHeader.h
Hdf5/Hdf5FileHeader.cpp

Public Types

Public Member Functions

Static Public Member Functions

Private Attributes

Static Private Attributes

Detailed Description

Member Enumeration Documentation

◆ FileHeaderItems

◆ FileType

◆ FileVersion

Constructor & Destructor Documentation

◆ Hdf5FileHeader() [1/2]

◆ Hdf5FileHeader() [2/2]

◆ ~Hdf5FileHeader()

Member Function Documentation

◆ checkMajorFileVersion()

◆ checkMinorFileVersion()

◆ getExecutionTimes()

◆ getFileMajorVersion()

◆ getFileMinorVersion()

◆ getFileType()

◆ getFileVersion()

◆ readHeaderFromCheckpointFile()

◆ readHeaderFromInputFile()

◆ readHeaderFromOutputFile()

◆ setActualCreationTime()

◆ setCodeName()

◆ setExecutionTimes()

◆ setFileType()

◆ setHostName()

◆ setMemoryConsumption()

◆ setNumberOfCores()

◆ writeHeaderToCheckpointFile()

◆ writeHeaderToOutputFile()

Member Data Documentation

◆ sHeaderNames
