MatrixContainer Class Reference

Class implementing the matrix container. More...

#include <MatrixContainer.h>

Collaboration diagram for MatrixContainer:
Collaboration graph
[legend]

Public Types

enum  MatrixIdx {
  MatrixIdx::kKappa, MatrixIdx::kC2, MatrixIdx::kP, MatrixIdx::kRhoX,
  MatrixIdx::kRhoY, MatrixIdx::kRhoZ, MatrixIdx::kUxSgx, MatrixIdx::kUySgy,
  MatrixIdx::kUzSgz, MatrixIdx::kDuxdx, MatrixIdx::kDuydy, MatrixIdx::kDuzdz,
  MatrixIdx::kRho0, MatrixIdx::kDtRho0Sgx, MatrixIdx::kDtRho0Sgy, MatrixIdx::kDtRho0Sgz,
  MatrixIdx::kDdxKShiftPosR, MatrixIdx::kDdyKShiftPos, MatrixIdx::kDdzKShiftPos, MatrixIdx::kDdxKShiftNegR,
  MatrixIdx::kDdyKShiftNeg, MatrixIdx::kDdzKShiftNeg, MatrixIdx::kPmlXSgx, MatrixIdx::kPmlYSgy,
  MatrixIdx::kPmlZSgz, MatrixIdx::kPmlX, MatrixIdx::kPmlY, MatrixIdx::kPmlZ,
  MatrixIdx::kBOnA, MatrixIdx::kAbsorbTau, MatrixIdx::kAbsorbEta, MatrixIdx::kAbsorbNabla1,
  MatrixIdx::kAbsorbNabla2, MatrixIdx::kSensorMaskIndex, MatrixIdx::kSensorMaskCorners, MatrixIdx::kInitialPressureSourceInput,
  MatrixIdx::kPressureSourceInput, MatrixIdx::kTransducerSourceInput, MatrixIdx::kVelocityXSourceInput, MatrixIdx::kVelocityYSourceInput,
  MatrixIdx::kVelocityZSourceInput, MatrixIdx::kPressureSourceIndex, MatrixIdx::kVelocitySourceIndex, MatrixIdx::kDelayMask,
  MatrixIdx::kDxudxn, MatrixIdx::kDyudyn, MatrixIdx::kDzudzn, MatrixIdx::kDxudxnSgx,
  MatrixIdx::kDyudynSgy, MatrixIdx::kDzudznSgz, MatrixIdx::kUxShifted, MatrixIdx::kUyShifted,
  MatrixIdx::kUzShifted, MatrixIdx::kXShiftNegR, MatrixIdx::kYShiftNegR, MatrixIdx::kZShiftNegR,
  MatrixIdx::kTemp1Real3D, MatrixIdx::kTemp2Real3D, MatrixIdx::kTemp3Real3D, MatrixIdx::kTempFftwX,
  MatrixIdx::kTempFftwY, MatrixIdx::kTempFftwZ, MatrixIdx::kTempFftwShift
}
 Matrix identifers of all matrices in the k-space code. More...


Public Member Functions

 MatrixContainer ()
 Constructor. More...

 MatrixContainer (const MatrixContainer &)=delete
 Copy constructor is not allowed.

 ~MatrixContainer ()
 Destructor. More...

MatrixContainer & operator= (const MatrixContainer &)=delete
 Operator = is not allowed.

size_t size () const
 Get the number of matrices in the container. More...

bool empty () const
 Is the container empty? More...

MatrixRecord & operator[] (const MatrixIdx matrixIdx)
 operator[] More...

template<typename T >
T & getMatrix (const MatrixIdx matrixIdx)
 Get the matrix with a specific type from the container. More...

void createMatrices ()
 Create all matrix objects in the container. More...

void addMatrices ()
 Populate the container based on the simulation type. More...

void freeMatrices ()
 Destroy and free all matrices. More...

void loadDataFromInputFile ()
 Load all marked matrices from the input HDF5 file. More...

void loadDataFromCheckpointFile ()
 Load selected matrices from the checkpoint HDF5 file. More...

void storeDataIntoCheckpointFile ()
 Store selected matrices into the checkpoint file. More...


Private Attributes

std::map< MatrixIdx, MatrixRecord > mContainer
 Map holding the container.


Detailed Description

This container is responsible to maintain all the matrices in the code except the output streams. The matrices are allocated, freed, loaded stored and check-pointed from here.

Definition at line 49 of file MatrixContainer.h.

Member Enumeration Documentation

◆ MatrixIdx

enum MatrixContainer::MatrixIdx
strong
Enumerator
kKappa

Kappa matrix.

kC2

c^2 matrix.

kP

Pressure matrix.

kRhoX

Acoustic density x.

kRhoY

Acoustic density y.

kRhoZ

Acoustic density z.

kUxSgx

Velocity x on staggered grid.

kUySgy

Velocity y on staggered grid.

kUzSgz

Velocity z on staggered grid.

kDuxdx

Acoustic acceleration x.

kDuydy

Acoustic acceleration y.

kDuzdz

Acoustic acceleration z.

kRho0

Initial velocity.

kDtRho0Sgx

dt / initial velocity on staggered grid x.

kDtRho0Sgy

dt / initial velocity on staggered grid y.

kDtRho0Sgz

dt / initial velocity on staggered grid z.

kDdxKShiftPosR

Positive Fourier shift in x.

kDdyKShiftPos

Positive Fourier shift in y.

kDdzKShiftPos

Positive Fourier shift in z.

kDdxKShiftNegR

Negative Fourier shift in x.

kDdyKShiftNeg

Negative Fourier shift in y.

kDdzKShiftNeg

Negative Fourier shift in z.

kPmlXSgx

PML on staggered grid x.

kPmlYSgy

PML on staggered grid y.

kPmlZSgz

PML on staggered grid z.

kPmlX

PML in x.

kPmlY

PML in y.

kPmlZ

PML in z.

kBOnA

Nonlinear coefficient.

kAbsorbTau

Absorbing coefficient Tau.

kAbsorbEta

Absorbing coefficient Eau.

kAbsorbNabla1

Absorbing coefficient Nabla 1.

kAbsorbNabla2

Absorbing coefficient Nabla 2.

kSensorMaskIndex

Linear sensor mask.

kSensorMaskCorners

Cuboid corners sensor mask.

kInitialPressureSourceInput

Initial pressure source data.

kPressureSourceInput

Pressure source input data.

kTransducerSourceInput

Transducer source input data.

kVelocityXSourceInput

Velocity x source input data.

kVelocityYSourceInput

Velocity y source input data.

kVelocityZSourceInput

Velocity z source input data.

kPressureSourceIndex

Pressure source geometry data.

kVelocitySourceIndex

Velocity source geometry data.

kDelayMask

Delay mask for many types sources.

kDxudxn

Non uniform grid acoustic velocity in x.

kDyudyn

Non uniform grid acoustic velocity in y.

kDzudzn

Non uniform grid acoustic velocity in z.

kDxudxnSgx

Non uniform grid acoustic velocity on staggered grid x.

kDyudynSgy

Non uniform grid acoustic velocity on staggered grid y.

kDzudznSgz

Non uniform grid acoustic velocity on staggered grid z.

kUxShifted

velocity shift for non-staggered velocity in x.

kUyShifted

velocity shift for non-staggered velocity in y.

kUzShifted

velocity shift for non-staggered velocity in z.

kXShiftNegR

Negative shift for non-staggered velocity in x.

kYShiftNegR

Negative shift for non-staggered velocity in y.

kZShiftNegR

Negative shift for non-staggered velocity in z.

kTemp1Real3D

3D temporary matrix.

kTemp2Real3D

3D temporary matrix.

kTemp3Real3D

3D temporary matrix.

kTempFftwX

Temporary matrix for 1D fft in x.

kTempFftwY

Temporary matrix for 1D fft in y.

kTempFftwZ

Temporary matrix for 1D fft in z.

kTempFftwShift

Temporary matrix for fft shift.

Definition at line 56 of file MatrixContainer.h.

Constructor & Destructor Documentation

◆ MatrixContainer()

MatrixContainer::MatrixContainer ( )

Constructor.

Definition at line 54 of file MatrixContainer.cpp.

◆ ~MatrixContainer()

MatrixContainer::~MatrixContainer ( )

Destructor. No need for virtual destructor (no polymorphism).

Definition at line 66 of file MatrixContainer.cpp.

Member Function Documentation

◆ addMatrices()

void MatrixContainer::addMatrices ( )

This function creates the list of matrices being used in the simulation. It is done based on the simulation parameters. All matrices records are created here.

Definition at line 128 of file MatrixContainer.cpp.

◆ createMatrices()

void MatrixContainer::createMatrices ( )
Exceptions
std::bad_alloc- Usually due to out of memory.
std::invalid_argument- If this routine is called more than once.
std::invalid_argument- If matrix type is unknown.

Create all matrix objects in the container.

Definition at line 76 of file MatrixContainer.cpp.

◆ empty()

bool MatrixContainer::empty ( ) const
inline
Returns
true - If the container is empty.

Definition at line 223 of file MatrixContainer.h.

◆ freeMatrices()

void MatrixContainer::freeMatrices ( )

Free all matrix objects.

Definition at line 419 of file MatrixContainer.cpp.

◆ getMatrix()

template<typename T >
T& MatrixContainer::getMatrix ( const MatrixIdx  matrixIdx)
inline

This template routine returns the reference to the matrix re-casted to the specific class type.

Parameters
[in]matrixIdx- Matrix identifier,
Returns
Reference to the Matrix,

Definition at line 245 of file MatrixContainer.h.

◆ loadDataFromCheckpointFile()

void MatrixContainer::loadDataFromCheckpointFile ( )

Load selected matrices from the checkpoint HDF5 file.

Definition at line 452 of file MatrixContainer.cpp.

◆ loadDataFromInputFile()

void MatrixContainer::loadDataFromInputFile ( )

Load all marked matrices from the input HDF5 file.

Definition at line 435 of file MatrixContainer.cpp.

◆ operator[]()

MatrixRecord& MatrixContainer::operator[] ( const MatrixIdx  matrixIdx)
inline
Parameters
[in]matrixIdx- Matrix identifier
Returns
Matrix record.

Definition at line 233 of file MatrixContainer.h.

◆ size()

size_t MatrixContainer::size ( ) const
inline
Returns
Number of matrices in the container.

Definition at line 214 of file MatrixContainer.h.

◆ storeDataIntoCheckpointFile()

void MatrixContainer::storeDataIntoCheckpointFile ( )

Store selected matrices into the checkpoint file.

Definition at line 469 of file MatrixContainer.cpp.

The documentation for this class was generated from the following files:
