The class for complex matrices. More...

#include <ComplexMatrix.h>

Inheritance diagram for TComplexMatrix:

Collaboration diagram for TComplexMatrix:

Public Member Functions
	TComplexMatrix (const TDimensionSizes &DimensionSizes)
	Constructor. More...

virtual	~TComplexMatrix ()
	Destructor.

TFloatComplex &	operator[] (const size_t &index)
	operator []. More...

const TFloatComplex &	operator[] (const size_t &index) const
	operator [], constant version. More...

TFloatComplex &	GetElementFrom3D (const size_t X, const size_t Y, const size_t Z)
	Get element from 3D matrix. More...

const TFloatComplex &	GetElementFrom3D (const size_t X, const size_t Y, const size_t Z) const
	Get element from 3D matrix, constant version. More...

virtual void	ReadDataFromHDF5File (THDF5_File &HDF5_File, const char *MatrixName)
	Load data from the HDF5_File. More...

virtual void	WriteDataToHDF5File (THDF5_File &HDF5_File, const char *MatrixName, const size_t CompressionLevel)
	Write data into the HDF5_File. More...

Public Member Functions inherited from TBaseFloatMatrix
	TBaseFloatMatrix ()
	Default constructor.

virtual TDimensionSizes	GetDimensionSizes () const
	Get dimension sizes of the matrix.

virtual size_t	GetTotalElementCount () const
	Get element count of the matrix.

virtual size_t	GetTotalAllocatedElementCount () const
	Get total allocated element count (might differ from total element count used for the simulation because of padding).

virtual	~TBaseFloatMatrix ()
	Destructor.

virtual void	CopyData (const TBaseFloatMatrix &src)
	Copy data from other matrix with the same size. More...

virtual void	ZeroMatrix ()
	Zero all elements of the matrix (NUMA first touch). More...

virtual void	ScalarDividedBy (const float scalar)
	Divide scalar/ matrix_element[i]. More...

virtual float *	GetRawData ()
	Get raw data out of the class (for direct kernel access).

virtual const float *	GetRawData () const
	Get raw data out of the class (for direct kernel access).

Public Member Functions inherited from TBaseMatrix
	TBaseMatrix ()
	Default constructor.

virtual	~TBaseMatrix ()
	Destructor.

Protected Member Functions
	TComplexMatrix ()
	Default constructor not allowed for public.

	TComplexMatrix (const TComplexMatrix &src)
	Copy constructor not allowed for public.

TComplexMatrix &	operator= (const TComplexMatrix &src)
	Operator not allowed for public.

virtual void	InitDimensions (const TDimensionSizes &DimensionSizes)
	Initialize dimension sizes and related structures. More...

Protected Member Functions inherited from TBaseFloatMatrix
virtual void	AllocateMemory ()
	Memory allocation. More...

virtual void	FreeMemory ()
	Memory deallocation. More...

	TBaseFloatMatrix (const TBaseFloatMatrix &src)
	Copy constructor is not directly allowed.

TBaseFloatMatrix &	operator= (const TBaseFloatMatrix &src)
	operator = is not directly allowed.

Additional Inherited Members
Protected Attributes inherited from TBaseFloatMatrix
size_t	pTotalElementCount
	Total number of elements.

size_t	pTotalAllocatedElementCount
	Total number of allocated elements (in terms of floats).

struct TDimensionSizes	pDimensionSizes
	Dimension sizes.

size_t	pDataRowSize
	Size of a 1D row in X dimension.

size_t	p2DDataSliceSize
	Size of a 2D slab (X,Y).

float *	pMatrixData
	Raw matrix data.

Detailed Description

The class for complex matrices.

Definition at line 64 of file ComplexMatrix.h.

Constructor & Destructor Documentation

TComplexMatrix::TComplexMatrix ( const TDimensionSizes & DimensionSizes )

Constructor.

Parameters

[in] DimensionSizes - Dimension sizes

Definition at line 58 of file ComplexMatrix.cpp.

Here is the call graph for this function:

Member Function Documentation

TFloatComplex& TComplexMatrix::GetElementFrom3D	(	const size_t	X,
		const size_t	Y,
		const size_t	Z
	)

inline

Get element from 3D matrix.

Parameters

[in]	X	- X dimension
[in]	Y	- Y dimension
[in]	Z	- Z dimension

Returns: a complex element of the class

Definition at line 107 of file ComplexMatrix.h.

const TFloatComplex& TComplexMatrix::GetElementFrom3D	(	const size_t	X,
		const size_t	Y,
		const size_t	Z
	)		const

inline

Get element from 3D matrix, constant version.

Parameters

[in]	X	- X dimension
[in]	Y	- Y dimension
[in]	Z	- Z dimension

Returns: a complex element of the class

Definition at line 122 of file ComplexMatrix.h.

void TComplexMatrix::InitDimensions ( const TDimensionSizes & DimensionSizes )

protectedvirtual

Initialize matrix dimension sizes.

Parameters

[in] DimensionSizes

Definition at line 160 of file ComplexMatrix.cpp.

Here is the caller graph for this function:

TFloatComplex& TComplexMatrix::operator[] ( const size_t & index )

inline

operator [].

Parameters

[in] index - 1D index into the array

Returns: - element of the matrix

Definition at line 83 of file ComplexMatrix.h.

const TFloatComplex& TComplexMatrix::operator[] ( const size_t & index ) const

inline

operator [], constant version.

Parameters

[in] index - 1D index into the array

Returns: element of the matrix

Definition at line 94 of file ComplexMatrix.h.

void TComplexMatrix::ReadDataFromHDF5File	(	THDF5_File &	HDF5_File,
		const char *	MatrixName
	)

virtual

Read data from HDF5 file (do some basic checks). Only from the root group.

Exceptions

ios::failure when there is a problem

Parameters

[in]	HDF5_File	- HDF5 file
[in]	MatrixName	- HDF5 dataset name

Implements TBaseMatrix.

Definition at line 75 of file ComplexMatrix.cpp.

Here is the call graph for this function:

void TComplexMatrix::WriteDataToHDF5File	(	THDF5_File &	HDF5_File,
		const char *	MatrixName,
		const size_t	CompressionLevel
	)

virtual

Write data to HDF5 file (only from the root group).

Exceptions

ios::failure an exception what the operation fails

Parameters

[in]	HDF5_File	- HDF5 file handle
[in]	MatrixName	- HDF5 dataset name
[in]	CompressionLevel	- Compression level for the dataset

Implements TBaseMatrix.

Definition at line 114 of file ComplexMatrix.cpp.

Here is the call graph for this function:

The documentation for this class was generated from the following files:

MatrixClasses/ComplexMatrix.h
MatrixClasses/ComplexMatrix.cpp
