Class for HDF5 header. More...

#include <HDF5_File.h>

Collaboration diagram for THDF5_FileHeader:

Public Types
enum	THDF5_FileHeaderItems { hdf5_fhi_created_by = 0, hdf5_fhi_creation_date = 1, hdf5_fhi_file_description = 2, hdf5_fhi_major_version = 3, hdf5_fhi_minor_version = 4, hdf5_fhi_file_type = 5, hdf5_fhi_host_name = 6, hdf5_fhi_total_memory_consumption = 7, hdf5_fhi_peak_core_memory_consumption = 8, hdf5_fhi_total_execution_time = 9, hdf5_fhi_data_load_time = 10, hdf5_fhi_preprocessing_time = 11, hdf5_fhi_simulation_time = 12, hdf5_fhi_postprocessing_time = 13, hdf5_fhi_number_of_cores = 14 }
	List of all header items.

enum	THDF5_FileType { hdf5_ft_input = 0, hdf5_ft_output = 1, hdf5_ft_checkpoint = 2, hdf5_ft_unknown = 3 }
	HDF5 file type.

enum	THDF5_FileVersion { hdf5_fv_10 = 0, hdf5_fv_11 = 1, hdf5_fv_unknown = 2 }
	HDF5 file version.

Public Member Functions
	THDF5_FileHeader ()
	Constructor. More...

	THDF5_FileHeader (const THDF5_FileHeader &other)
	Copy constructor. More...

	~THDF5_FileHeader ()
	Destructor. More...

void	ReadHeaderFromInputFile (THDF5_File &InputFile)
	Read header from the input file. More...

void	ReadHeaderFromOutputFile (THDF5_File &OutputFile)
	Read Header from output file (necessary for checkpoint-restart). More...

void	ReadHeaderFromCheckpointFile (THDF5_File &CheckpointFile)
	Read Header from checkpoint file (necessary for checkpoint-restart). More...

void	WriteHeaderToOutputFile (THDF5_File &OutputFile)
	Write header to the output file. More...

void	WriteHeaderToCheckpointFile (THDF5_File &CheckpointFile)
	Write header to the output file. More...

void	SetCodeName (const string &CodeName)
	Set code name. More...

void	SetActualCreationTime ()
	Set creation time. More...

void	SetMajorFileVersion ()
	Set major file version.

void	SetMinorFileVersion ()
	Set minor file version.

THDF5_FileVersion	GetFileVersion ()
	Set major file version in a string. More...

bool	CheckMajorFileVersion ()
	Check major file version. More...

bool	CheckMinorFileVersion ()
	Check minor file version. More...

THDF5_FileHeader::THDF5_FileType	GetFileType ()
	Get File type. More...

void	SetFileType (const THDF5_FileHeader::THDF5_FileType FileType)
	Set file type. More...

void	SetHostName ()
	Set host name. More...

void	SetMemoryConsumption (size_t TotalMemory)
	Set memory consumption. More...

void	SetExecutionTimes (const double TotalTime, const double LoadTime, const double PreProcessingTime, const double SimulationTime, const double PostprocessingTime)
	Set execution times. More...

void	GetExecutionTimes (double &TotalTime, double &LoadTime, double &PreProcessingTime, double &SimulationTime, double &PostprocessingTime)
	Get execution times stored in the output file header. More...

void	SetNumberOfCores ()
	Set number of cores. More...

Static Public Member Functions
static string	GetCurrentHDF5_MajorVersion ()
	Get string version of current Major version. More...

static string	GetCurrentHDF5_MinorVersion ()
	Get string version of current Minor version. More...

Private Member Functions
void	PopulateHeaderFileMap ()
	Populate the map with the header items. More...

Private Attributes
map< THDF5_FileHeaderItems, string >	HDF5_FileHeaderValues
	map for the header values.

map< THDF5_FileHeaderItems, string >	HDF5_FileHeaderNames
	map for the header names.

Static Private Attributes
static const string	HDF5_FileTypesNames [] = {"input","output", "checkpoint", "unknown"}
	String representation of different file types.

static const string	HDF5_MajorFileVersionsNames [] = {"1"}
	String representations of Major file versions.

static const string	HDF5_MinorFileVersionsNames [] = {"0","1"}
	String representations of Major file versions.

Detailed Description

This class manages all information that can be stored in the input output or checkpoint file.

Definition at line 749 of file HDF5_File.h.

Constructor & Destructor Documentation

THDF5_FileHeader::THDF5_FileHeader ( )

Constructor.

Definition at line 1295 of file HDF5_File.cpp.

Here is the call graph for this function:

THDF5_FileHeader::THDF5_FileHeader ( const THDF5_FileHeader & other )

Copy constructor.

Parameters

[in] other

Definition at line 1307 of file HDF5_File.cpp.

THDF5_FileHeader::~THDF5_FileHeader ( )

Destructor.

Definition at line 1319 of file HDF5_File.cpp.

Member Function Documentation

bool THDF5_FileHeader::CheckMajorFileVersion ( )

inline

Check major file version.

Returns: true if ok

Definition at line 863 of file HDF5_File.h.

Here is the caller graph for this function:

bool THDF5_FileHeader::CheckMinorFileVersion ( )

inline

Check minor file version.

Returns: true if ok

Definition at line 872 of file HDF5_File.h.

Here is the caller graph for this function:

static string THDF5_FileHeader::GetCurrentHDF5_MajorVersion ( )

inlinestatic

Get string version of current Major version.

Returns: current version

Definition at line 829 of file HDF5_File.h.

Here is the caller graph for this function:

static string THDF5_FileHeader::GetCurrentHDF5_MinorVersion ( )

inlinestatic

Get string version of current Minor version.

Returns: current minor version

Definition at line 839 of file HDF5_File.h.

Here is the caller graph for this function:

void THDF5_FileHeader::GetExecutionTimes	(	double &	TotalTime,
		double &	LoadTime,
		double &	PreProcessingTime,
		double &	SimulationTime,
		double &	PostprocessingTime
	)

Get execution times stored in the output file header

Parameters

[out]	TotalTime
[out]	LoadTime
[out]	PreProcessingTime
[out]	SimulationTime
[out]	PostprocessingTime

Definition at line 1668 of file HDF5_File.cpp.

Here is the caller graph for this function:

THDF5_FileHeader::THDF5_FileType THDF5_FileHeader::GetFileType ( )

Get File type.

Returns: FileType

Definition at line 1514 of file HDF5_File.cpp.

Here is the caller graph for this function:

THDF5_FileHeader::THDF5_FileVersion THDF5_FileHeader::GetFileVersion ( )

Get File Version an enum

Returns: file version as an enum

Definition at line 1543 of file HDF5_File.cpp.

void THDF5_FileHeader::PopulateHeaderFileMap ( )

private

Create map with names for the header.

Definition at line 1705 of file HDF5_File.cpp.

Here is the caller graph for this function:

void THDF5_FileHeader::ReadHeaderFromCheckpointFile ( THDF5_File & CheckpointFile )

Read the file header form the checkpoint file. We need the header to verify the file version and type

Parameters

[in] CheckpointFile

Definition at line 1413 of file HDF5_File.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

void THDF5_FileHeader::ReadHeaderFromInputFile ( THDF5_File & InputFile )

Read header from the input file.

Parameters

[in] InputFile - Input file to read from

Definition at line 1332 of file HDF5_File.cpp.

Here is the call graph for this function:

void THDF5_FileHeader::ReadHeaderFromOutputFile ( THDF5_File & OutputFile )

Read header from output file (necessary for checkpoint-restart). Read only execution times (the others are read from the input file, or calculated based on the very last leg of the simulation). This function is called only if checkpoint-restart is enabled.

Parameters

[in] OutputFile

Definition at line 1374 of file HDF5_File.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

void THDF5_FileHeader::SetActualCreationTime ( )

Set actual date and time.

Definition at line 1565 of file HDF5_File.cpp.

Here is the caller graph for this function:

void THDF5_FileHeader::SetCodeName ( const string & CodeName )

inline

Set code name to the header.

Parameters

CodeName - code version

Definition at line 816 of file HDF5_File.h.

Here is the caller graph for this function:

void THDF5_FileHeader::SetExecutionTimes	(	const double	TotalTime,
		const double	LoadTime,
		const double	PreProcessingTime,
		const double	SimulationTime,
		const double	PostprocessingTime
	)
