TLongMatrix Class Reference

The class for 64b integers. It is used for index mask into float matrices.

#include <LongMatrix.h>

Inheritance diagram for TLongMatrix:

Collaboration diagram for TLongMatrix:

List of all members.

Public Member Functions
	TLongMatrix (struct TDimensionSizes DimensionSizes)
	Constructor.
virtual	~TLongMatrix ()
	Destructor.
virtual void	ReadDataFromHDF5File (THDF5_File &HDF5_File, const char *MatrixName)
	Read data from the HDF5 file.
virtual void	WriteDataToHDF5File (THDF5_File &HDF5_File, const char *MatrixName, const int CompressionLevel)
	Write data into the HDF5 file.
long &	operator[] (const size_t &index)
long &	GetElementFrom3D (const size_t X, const size_t Y, const size_t Z)
void	RecomputeIndices ()
	Recompute indices MATALAB->C++.
Protected Member Functions
	TLongMatrix ()
	Default constructor not allowed for public.
	TLongMatrix (const TLongMatrix &src)
	Copy constructor not allowed for public.
TLongMatrix &	operator= (const TLongMatrix &src)
	Operator = not allowed for public.

---

Detailed Description

Definition at line 43 of file LongMatrix.h.

---

Constructor & Destructor Documentation

TLongMatrix::TLongMatrix

(

struct TDimensionSizes

DimensionSizes

)

Constructor

Parameters:

[in]

DimensionSizes

- Dimension sizes

Definition at line 59 of file LongMatrix.cpp.

Here is the call graph for this function:

---

Member Function Documentation

long& TLongMatrix::GetElementFrom3D	(	const size_t	X,
		const size_t	Y,
		const size_t	Z
	)		[inline]

Get element form the 3D matrix

Parameters:

X	- X dimension
Y	- Y dimension
Z	- Z dimension

Returns:

an alement

Definition at line 74 of file LongMatrix.h.

long& TLongMatrix::operator[]

(

const size_t &

index

)

[inline]

Operator []

Parameters:

index

- 1D index into the matrix

Returns:

Value of the index

Definition at line 62 of file LongMatrix.h.

void TLongMatrix::ReadDataFromHDF5File	(	THDF5_File &	HDF5_File,
		const char *	MatrixName
	)		[virtual]

Read data from HDF5 file

Exceptions:

ios:failure

if there's an error

Parameters:

HDF5_File	- HDF5 file handle
MatrixName	- HDF5 dataset name

Reimplemented from TBaseMatrix.

Definition at line 91 of file LongMatrix.cpp.

Here is the call graph for this function:

void TLongMatrix::RecomputeIndices

(

)

Recompute indeces, MATLAB -> C++

Definition at line 119 of file LongMatrix.cpp.

Here is the caller graph for this function:

void TLongMatrix::WriteDataToHDF5File	(	THDF5_File &	HDF5_File,
		const char *	MatrixName,
		const int	CompressionLevel
	)		[virtual]

Write data to HDF5 file

Exceptions:

ios:failure

Parameters:

[in]	HDF5_File	- HDF5 file handle
[in]	MatrixName	- HDF5 Dataset name
[in]	CompressionLevel	- Compression level

Reimplemented from TBaseMatrix.

Definition at line 139 of file LongMatrix.cpp.

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• MatrixClasses/LongMatrix.h
• MatrixClasses/LongMatrix.cpp
