The class for real matrices. More...

#include <RealMatrix.h>

Inheritance diagram for TRealMatrix:

Collaboration diagram for TRealMatrix:

Public Member Functions
	TRealMatrix (const TDimensionSizes &DimensionSizes)
	Constructor. More...

virtual	~TRealMatrix ()
	Destructor.

virtual void	ReadDataFromHDF5File (THDF5_File &HDF5_File, const char *MatrixName)
	Read data from the HDF5 file - only from the root group. More...

virtual void	WriteDataToHDF5File (THDF5_File &HDF5_File, const char *MatrixName, const size_t CompressionLevel)
	Write data into the HDF5 file. More...

float &	operator[] (const size_t &index)
	operator []. More...

const float &	operator[] (const size_t &index) const
	operator [], constant version. More...

float &	GetElementFrom3D (const size_t X, const size_t Y, const size_t Z)
	Get element from 3D matrix. More...

Public Member Functions inherited from TBaseFloatMatrix
	TBaseFloatMatrix ()
	Default constructor.

virtual TDimensionSizes	GetDimensionSizes () const
	Get dimension sizes of the matrix.

virtual size_t	GetTotalElementCount () const
	Get element count of the matrix.

virtual size_t	GetTotalAllocatedElementCount () const
	Get total allocated element count (might differ from total element count used for the simulation because of padding).

virtual	~TBaseFloatMatrix ()
	Destructor.

virtual void	CopyData (const TBaseFloatMatrix &src)
	Copy data from other matrix with the same size. More...

virtual void	ZeroMatrix ()
	Zero all elements of the matrix (NUMA first touch). More...

virtual void	ScalarDividedBy (const float scalar)
	Divide scalar/ matrix_element[i]. More...

virtual float *	GetRawData ()
	Get raw data out of the class (for direct kernel access).

virtual const float *	GetRawData () const
	Get raw data out of the class (for direct kernel access).

Public Member Functions inherited from TBaseMatrix
	TBaseMatrix ()
	Default constructor.

virtual	~TBaseMatrix ()
	Destructor.

Protected Member Functions
	TRealMatrix ()
	Default constructor is not allowed for public.

	TRealMatrix (const TRealMatrix &src)
	Copy constructor not allowed for public.

TRealMatrix &	operator= (const TRealMatrix &src)
	Operator = is not allowed for public.

virtual void	InitDimensions (const TDimensionSizes &DimensionSizes)
	Init dimension. More...

Protected Member Functions inherited from TBaseFloatMatrix
virtual void	AllocateMemory ()
	Memory allocation. More...

virtual void	FreeMemory ()
	Memory deallocation. More...

	TBaseFloatMatrix (const TBaseFloatMatrix &src)
	Copy constructor is not directly allowed.

TBaseFloatMatrix &	operator= (const TBaseFloatMatrix &src)
	operator = is not directly allowed.

Static Private Attributes
static const size_t	ChunkSize_1D_4MB = 1048576
	Number of elements to get 4MB block of data.

static const size_t	ChunkSize_1D_1MB = 262144
	Number of elements to get 1MB block of data.

static const size_t	ChunkSize_1D_256KB = 65536
	Number of elements to get 256KB block of data.

Additional Inherited Members
Protected Attributes inherited from TBaseFloatMatrix
size_t	pTotalElementCount
	Total number of elements.

size_t	pTotalAllocatedElementCount
	Total number of allocated elements (in terms of floats).

struct TDimensionSizes	pDimensionSizes
	Dimension sizes.

size_t	pDataRowSize
	Size of a 1D row in X dimension.

size_t	p2DDataSliceSize
	Size of a 2D slab (X,Y).

float *	pMatrixData
	Raw matrix data.

Detailed Description

The class for real matrices (floats)

Definition at line 48 of file RealMatrix.h.

Constructor & Destructor Documentation

TRealMatrix::TRealMatrix ( const TDimensionSizes & DimensionSizes )

Constructor.

Parameters

[in] DimensionSizes - Dimension sizes

Definition at line 60 of file RealMatrix.cpp.

Here is the call graph for this function:

Member Function Documentation

float& TRealMatrix::GetElementFrom3D	(	const size_t	X,
		const size_t	Y,
		const size_t	Z
	)

inline

Get element from 3D matrix.

Parameters

[in]	X	- X dimension
[in]	Y	- Y dimension
[in]	Z	- Z dimension

Returns: an element

Definition at line 101 of file RealMatrix.h.

void TRealMatrix::InitDimensions ( const TDimensionSizes & DimensionSizes )

protectedvirtual

Set necessary dimensions and auxiliary variables.

Parameters

[in] DimensionSizes - 3D Dimension sizes

Definition at line 171 of file RealMatrix.cpp.

Here is the caller graph for this function:

float& TRealMatrix::operator[] ( const size_t & index )

inline

operator [].

Parameters

[in] index - 1D index

Returns: an element

Definition at line 76 of file RealMatrix.h.

const float& TRealMatrix::operator[] ( const size_t & index ) const

inline

operator [], constant version.

Parameters

[in] index - 1D index

Returns: an element

Definition at line 88 of file RealMatrix.h.

void TRealMatrix::ReadDataFromHDF5File	(	THDF5_File &	HDF5_File,
		const char *	MatrixName
	)

virtual

Read data data from HDF5 file (only from the root group).

Parameters

[in]	HDF5_File	- HDF5 file
[in]	MatrixName	- HDF5 dataset name

Exceptions

ios::failure if error occurred.

Implements TBaseMatrix.

Definition at line 77 of file RealMatrix.cpp.

Here is the call graph for this function:

void TRealMatrix::WriteDataToHDF5File	(	THDF5_File &	HDF5_File,
		const char *	MatrixName,
		const size_t	CompressionLevel
	)

virtual

Write data to HDF5 file (only from the root group)

Parameters

[in]	HDF5_File	- HDF5 file
[in]	MatrixName	- HDF5 Matrix name
[in]	CompressionLevel	- Compression level

Exceptions

ios::failure if an error occurred

Implements TBaseMatrix.

Definition at line 114 of file RealMatrix.cpp.

Here is the call graph for this function:

Here is the caller graph for this function:

The documentation for this class was generated from the following files:

MatrixClasses/RealMatrix.h
MatrixClasses/RealMatrix.cpp
