Output stream for quantities sampled in the whole domain. More...

#include <WholeDomainOutputStream.h>

Inheritance diagram for WholeDomainOutputStream:

Collaboration diagram for WholeDomainOutputStream:

[legend]

Public Member Functions
	WholeDomainOutputStream ()=delete
	Default constructor not allowed.

	WholeDomainOutputStream (Hdf5File &file, MatrixName &datasetName, const RealMatrix &sourceMatrix, const ReduceOperator reductionOp, float *bufferToReuse=nullptr)
	Constructor links the HDF5 File, SourceMatrix, and SensorMask together. More...

	WholeDomainOutputStream (const WholeDomainOutputStream &)=delete
	Copy constructor not allowed.

virtual	~WholeDomainOutputStream ()
	Destructor. More...

WholeDomainOutputStream &	operator= (const WholeDomainOutputStream &)=delete
	operator= is not allowed.

virtual void	create ()
	Create a HDF5 stream and allocate data for it. More...

virtual void	reopen ()
	Reopen the output stream after restart and reload data. More...

virtual void	sample ()
	Sample data into buffer and apply reduction, or flush to disk (no sensor mask here). More...

virtual void	postProcess ()
	Apply post-processing on the buffer and flush it to the file. More...

virtual void	checkpoint ()
	Checkpoint the stream and close. More...

virtual void	close ()
	Close stream (apply post-processing if necessary, flush data and close). More...

Public Member Functions inherited from BaseOutputStream
	BaseOutputStream ()=delete
	Default constructor not allowed.

	BaseOutputStream (Hdf5File &file, MatrixName &rootObjectName, const RealMatrix &sourceMatrix, const ReduceOperator reduceOp, float *bufferToReuse=nullptr)
	Constructor. More...

	BaseOutputStream (const BaseOutputStream &src)
	Copy constructor not allowed.

virtual	~BaseOutputStream ()
	Destructor. More...

BaseOutputStream &	operator= (const BaseOutputStream &src)
	Operator = not allowed (we don't want any data movements).

Protected Member Functions
virtual void	flushBufferToFile ()
	Flush the buffer to the file. More...

Protected Member Functions inherited from BaseOutputStream
virtual void	allocateMemory ()
	Allocate memory using proper memory alignment. More...

virtual void	freeMemory ()
	Free memory. More...

Protected Attributes
hid_t	mDataset
	Handle to a HDF5 dataset.

size_t	mSampledTimeStep
	Time step to store (N/A for aggregated).

Protected Attributes inherited from BaseOutputStream
Hdf5File &	mFile
	Handle to HDF5 output file.

std::string	mRootObjectName
	HDF5 group/dataset in the output file where to store data in.

const RealMatrix &	mSourceMatrix
	Source matrix to be sampled.

const ReduceOperator	mReduceOp
	Reduction operator.

bool	mBufferReuse
	if true, the container reuses another matrix as scratch place, e.g. Temp_1_RS3D, Temp_2_RS3D, Temp_3_RS3D.

size_t	mBufferSize
	Buffer size.

float *	mStoreBuffer
	Temporary buffer for store - only if Buffer Reuse = false!

Additional Inherited Members
Public Types inherited from BaseOutputStream
enum	ReduceOperator { ReduceOperator::kNone, ReduceOperator::kRms, ReduceOperator::kMax, ReduceOperator::kMin }
	How to aggregate data. More...

Static Protected Attributes inherited from BaseOutputStream
static constexpr size_t	kChunkSize4MB = 1048576
	chunk size of 4MB in number of float elements.

Detailed Description

Output stream for quantities sampled in the whole domain. The data is stored in a single dataset (aggregated quantities only).

Definition at line 44 of file WholeDomainOutputStream.h.

Constructor & Destructor Documentation

◆ WholeDomainOutputStream()

WholeDomainOutputStream::WholeDomainOutputStream	(	Hdf5File &	file,
		MatrixName &	datasetName,
		const RealMatrix &	sourceMatrix,
		const ReduceOperator	reductionOp,
		float *	bufferToReuse = `nullptr`
	)

Parameters

[in]	file	- HDF5 file to write the output to
[in]	datasetName	- The name of the HDF5 group. This group contains datasets for particular cuboids
[in]	sourceMatrix	- Source matrix to be sampled
[in]	reductionOp	- Reduction operator
[in]	bufferToReuse	- If there is a memory space to be reused, provide a pointer

Constructor - links the HDF5 dataset and SourceMatrix.

Parameters

[in]	file	- HDF5 file to write the output to
[in]	datasetName	- The name of the HDF5 group. This group contains datasets for particular cuboids
[in]	sourceMatrix	- Source matrix to be sampled
[in]	reductionOp	- Reduction operator
[in]	bufferToReuse	- If there is a memory space to be reused, provide a pointer
