Class storing all parameters of the simulation. More...

#include <Parameters.h>

Collaboration diagram for Parameters:

[legend]

Public Types
enum	SensorMaskType { SensorMaskType::kIndex = 0, SensorMaskType::kCorners = 1 }
	Sensor mask type (linear or cuboid corners). More...

Public Member Functions
	Parameters (const Parameters &)=delete
	Copy constructor not allowed.

virtual	~Parameters ()
	Destructor. More...

Parameters &	operator= (const Parameters &)=delete
	operator= not allowed.

void	init (int argc, char **argv)
	Parse command line and read scalar values form the input file. More...

void	printSimulatoinSetup ()
	Print the simulation setup (all parameters). More...

bool	isPrintVersionOnly () const
	Shall the code print version and exit? More...

void	readScalarsFromInputFile ()
	Read scalar values from the input HDF5 file. More...

void	saveScalarsToOutputFile ()
	Save scalar values into the output HDF5 file. More...

std::string	getGitHash () const
	Get git hash of the code. More...

size_t	getNumberOfThreads () const
	Get number of CPU threads to use. More...

size_t	getCompressionLevel () const
	Get compression level. More...

size_t	getProgressPrintInterval () const
	Get progress print interval. More...

bool	isCheckpointEnabled () const
	Is checkpoint enabled? More...

size_t	getCheckpointInterval () const
	Get checkpoint interval. More...

Hdf5File &	getInputFile ()
	Get input file handle. More...

Hdf5File &	getOutputFile ()
	Get output file handle. More...

Hdf5File &	getCheckpointFile ()
	Get checkpoint file handle. More...

Hdf5FileHeader &	getFileHeader ()
	Get file header handle. More...

std::string	getInputFileName () const
	Get input file name. More...

std::string	getOutputFileName () const
	Get output file name. More...

std::string	getCheckpointFileName () const
	Get checkpoint file name. More...

DimensionSizes	getFullDimensionSizes () const
	Get full dimension sizes of the simulation (real classes). More...

DimensionSizes	getReducedDimensionSizes () const
	Get reduced dimension sizes of the simulation (complex classes). More...

size_t	getNt () const
	Get total number of time steps. More...

size_t	getTimeIndex () const
	Get actual simulation time step. More...

void	setTimeIndex (const size_t timeIndex)
	Set simulation time step - should be used only when recovering from checkpoint. More...

void	incrementTimeIndex ()
	Increment simulation time step.

float	getDt () const
	Get time step size. More...

float	getDx () const
	Get spatial displacement in x. More...

float	getDy () const
	Get spatial displacement in y. More...

float	getDz () const
	Get spatial displacement in z. More...

float	getCRef () const
	Get reference sound speed. More...

bool	getC0ScalarFlag () const
	Is sound speed in the medium homogeneous (scalar value)? More...

float	getC0Scalar () const
	Get scalar value of sound speed. More...

float	getC2Scalar () const
	Get scalar value of sound speed squared. More...

bool	getRho0ScalarFlag () const
	Is density in the medium homogeneous (scalar value)? More...

float	getRho0Scalar () const
	Get value of homogeneous medium density. More...

float	getRho0SgxScalar () const
	Get value of homogeneous medium density on staggered grid in x direction. More...

float	getDtRho0SgxScalar () const
	Get value of dt / rho0Sgx. More...

float	getRho0SgyScalar () const
	Get value of homogeneous medium density on staggered grid in y direction. More...

float	getDtRho0SgyScalar () const
	Get value of dt / rho0Sgy. More...

float	getRho0SgzScalar () const
	Get value of homogeneous medium density on staggered grid in z direction. More...

float	getDtRho0SgzScalar () const
	Get value of dt / rho0Sgz. More...

size_t	getNonUniformGridFlag () const
	Enable non uniform grid? - not implemented yet. More...

size_t	getAbsorbingFlag () const
	Is the simulation absrobing or lossless? More...

size_t	getNonLinearFlag () const
	Is the wave propagation nonlinear? More...

bool	getAlphaCoeffScalarFlag () const
	Is alpha absorption coefficient homogeneous (scalar value)? More...

float	getAlphaCoeffScalar () const
	Get value of alpha absorption coefficient. More...

float	getAlphaPower () const
	Get alpha power value for the absorption law. More...

float	getAbsorbEtaScalar () const
	Get absorb eta coefficient for homogeneous medium (scalar value)? More...

void	setAbsorbEtaScalar (const float absrobEta)
	Set absorb eta coefficient for homogeneous medium (scalar value). More...

float	getAbsorbTauScalar () const
	Get absorb tau coefficient for homogeneous medium. More...

void	setAbsorbTauScalar (const float absorbTau)
	Set absorb tau coefficient for homogeneous medium (scalar value). More...

bool	getBOnAScalarFlag () const
	Is nonlinear coefficient homogeneous in the medium (scalar value)? More...

float	getBOnAScalar () const
	Get nonlinear coefficient for homogenous medium. More...

size_t	getPmlXSize () const
	Get depth of the perfectly matched layer in x. More...

size_t	getPmlYSize () const
	Get depth of the perfectly matched layer in y. More...

size_t	getPmlZSize () const
	Get depth of the perfectly matched layer in z. More...

float	getPmlXAlpha () const
	Get Perfectly matched layer attenuation in x, not implemented. More...

float	getPmlYAlpha () const
	Get Perfectly matched layer attenuation in y, not implemented. More...

float	getPmlZAlpha () const
	Get Perfectly matched layer attenuation in z , not implemented. More...

size_t	getPressureSourceFlag () const
	Get pressure source flag. More...

size_t	getInitialPressureSourceFlag () const
	Get initial pressure source flag (p0). More...

size_t	getTransducerSourceFlag () const
	Get transducer source flag. More...

size_t	getVelocityXSourceFlag () const
	Get velocity in x source flag. More...

size_t	getVelocityYSourceFlag () const
	Get velocity in y source flag. More...

size_t	getVelocityZSourceFlag () const
	Get velocity in z source flag. More...

size_t	getPressureSourceIndexSize () const
	Get spatial size of the pressure source. More...

size_t	getTransducerSourceInputSize () const
	Get spatial size of the transducer source. More...

size_t	getVelocitySourceIndexSize () const
	Get spatial size of the velocity source. More...

size_t	getPressureSourceMode () const
	Get pressure source mode. More...

size_t	getPressureSourceMany () const
	Get number of time series in the pressure source. More...

size_t	getVelocitySourceMode () const
	Get velocity source mode. More...

size_t	getVelocitySourceMany () const
	Get number of time series in the velocity sources. More...

SensorMaskType	getSensorMaskType () const
	Get sensor mask type (linear or corners). More...

size_t	getSensorMaskIndexSize () const
	Get spatial size of the index sensor mask. More...

size_t	getSensorMaskCornersSize () const
	Get number of cuboids the sensor is composed of. More...

size_t	getSamplingStartTimeIndex () const
	Get start time index when sensor data collection begins. More...

bool	getStorePressureRawFlag () const
	Is -p or –p_raw specified at the command line? More...

bool	getStorePressureRmsFlag () const
	Is –p_rms set? More...

bool	getStorePressureMaxFlag () const
	Is –p_max set? More...

bool	getStorePressureMinFlag () const
	Is –p_min set? More...

bool	getStorePressureMaxAllFlag () const
	Is –p_max_all set? More...

bool	getStorePressureMinAllFlag () const
	Is –p_min_all set? More...

bool	getStorePressureFinalAllFlag () const
	Is –p_final set? More...

bool	getStoreVelocityRawFlag () const
	Is -u or –u_raw specified at the command line? More...

bool	getStoreVelocityNonStaggeredRawFlag () const
	Is –u_non_staggered_raw set? More...

bool	getStoreVelocityRmsFlag () const
	Is –u_rms set? More...

bool	getStoreVelocityMaxFlag () const
	Is –u_max set? More...

bool	getStoreVelocityMinFlag () const
	Is –u_min set? More...

bool	getStoreVelocityMaxAllFlag () const
	Is –u_max_all set? More...

bool	getStoreVelocityMinAllFlag () const
	Is –u_min set? More...

bool	getStoreVelocityFinalAllFlag () const
	Is –u_final set? More...

bool	getCopySensorMaskFlag () const
	Is –copy_mask set set? More...

Static Public Member Functions
static Parameters &	getInstance ()
	Get instance of the singleton class. More...

Protected Member Functions
	Parameters ()
	Constructor not allowed for public. More...

Private Attributes
CommandLineParameters	mCommandLineParameters
	Class with command line parameters.

Hdf5File	mInputFile
	Handle to the input HDF5 file.

Hdf5File	mOutputFile
	Handle to the output HDF5 file.

Hdf5File	mCheckpointFile
	Handle to the checkpoint HDF5 file.

Hdf5FileHeader	mFileHeader
	Handle to file header.

DimensionSizes	mFullDimensionSizes
	Full 3D dimension sizes.

DimensionSizes	mReducedDimensionSizes
	Reduced 3D dimension sizes.

size_t	mNt
	Total number of time steps.

size_t	mTimeIndex
	Actual time index (time step of the simulation).

float	mDt
	Time step size.

float	mDx
	Spatial displacement in x.

float	mDy
	Spatial displacement in y.

float	mDz
	Spatial displacement in z.

float	mCRef
	Reference sound speed.

bool	mC0ScalarFlag
	Is sound speed in the medium homogeneous?

float	mC0Scalar
	Scalar value of sound speed.

bool	mRho0ScalarFlag
	Is density in the medium homogeneous?

float	mRho0Scalar
	Homogeneous medium density.

float	mRho0SgxScalar
	Homogeneous medium density on staggered grid in x direction.

float	mRho0SgyScalar
	Homogeneous medium density on staggered grid in y direction.

float	mRho0SgzScalar
	Homogeneous medium density on staggered grid in z direction.

size_t	mNonUniformGridFlag
	Enable non uniform grid?

size_t	mAbsorbingFlag
	Is the simulation absrobing or lossless?

size_t	mNonLinearFlag
	Is the wave propagation nonlinear?

bool	mAlphaCoeffScalarFlag
	Is alpha absorption coefficient homogeneous?

float	mAlphaCoeffScalar
	Alpha absorption coefficient.

float	mAlphaPower
	Alpha power value for the absorption law.

float	mAbsorbEtaScalar
	Absorb eta coefficient for homogeneous medium.

float	mAbsorbTauScalar
	Absorb tau coefficient for homogeneous medium.

bool	mBOnAScalarFlag
	Is nonlinear coefficient homogeneous in the medium?

float	mBOnAScalar
	Nonlinear coefficient for homogenous medium.

size_t	mPmlXSize
	Depth of the perfectly matched layer in x.

size_t	mPmlYSize
	Depth of the perfectly matched layer in y.

size_t	mPmlZSize
	Depth of the perfectly matched layer in z.

float	mPmlXAlpha
	Perfectly matched layer attenuation in x.

float	mPmlYAlpha
	Perfectly matched layer attenuation in y.

float	mPmlZAlpha
	Perfectly matched layer attenuation in z.

size_t	mPressureSourceFlag
	Pressure source flag.

size_t	mInitialPressureSourceFlag
	Initial pressure source flag (p0).

size_t	mTransducerSourceFlag
	Transducer source flag.

size_t	mVelocityXSourceFlag
	Velocity in x source flag.

size_t	mVelocityYSourceFlag
	Velocity in y source flag.

size_t	mVelocityZSourceFlag
	Velocity in z source flag.

size_t	mPressureSourceIndexSize
	Spatial size of the pressure source.

size_t	mTransducerSourceInputSize
	Spatial size of the transducer source.

size_t	mVelocitySourceIndexSize
	Spatial size of the velocity source.

size_t	mPressureSourceMode
	Pressure source mode.

size_t	mPressureSourceMany
	Number of time series in the pressure source.

size_t	mVelocitySourceMode
	Velocity source mode.

size_t	mVelocitySourceMany
	Number of time series in the velocity sources.

SensorMaskType	mSensorMaskType
	Sensor mask type (index / corners).

size_t	mSensorMaskIndexSize
	How many elements there are in the linear mask.

size_t	mSensorMaskCornersSize
	Sensor_mask_corners_size - how many cuboids are in the mask.

Static Private Attributes
static bool	sParametersInstanceFlag = false
	Singleton flag.

static Parameters *	sPrametersInstance = nullptr
	Singleton instance.

Detailed Description

Class storing all parameters of the simulation.

Warning: This is a singleton class.

Definition at line 50 of file Parameters.h.

Member Enumeration Documentation

◆ SensorMaskType

enum Parameters::SensorMaskType

strong

Sensor mask type (linear or cuboid corners).

Enumerator
kIndex	Linear sensor mask.
kCorners	Cuboid corners sensor mask.

Definition at line 59 of file Parameters.h.

Constructor & Destructor Documentation

◆ ~Parameters()

Parameters::~Parameters ( )

virtual

Destructor.

Definition at line 70 of file Parameters.cpp.

◆ Parameters()

Parameters::Parameters ( )

protected

Constructor.

Definition at line 489 of file Parameters.cpp.

Member Function Documentation

◆ getAbsorbEtaScalar()

float Parameters::getAbsorbEtaScalar ( ) const

inline

Returns: Absorb eta coefficient.

Definition at line 340 of file Parameters.h.

◆ getAbsorbingFlag()

size_t Parameters::getAbsorbingFlag ( ) const

inline

Returns: 0 if the medium is lossless, 1 otherwise.

Definition at line 314 of file Parameters.h.

◆ getAbsorbTauScalar()

float Parameters::getAbsorbTauScalar ( ) const

inline

Returns: Absorb tau coefficient.

Definition at line 350 of file Parameters.h.

◆ getAlphaCoeffScalar()

float Parameters::getAlphaCoeffScalar ( ) const

inline

Returns: Alpha absorption coefficient.

Definition at line 330 of file Parameters.h.

◆ getAlphaCoeffScalarFlag()

bool Parameters::getAlphaCoeffScalarFlag ( ) const

inline

Returns: True if scalar.

Definition at line 325 of file Parameters.h.

◆ getAlphaPower()

float Parameters::getAlphaPower ( ) const

inline

Returns: Alpha power value.

Definition at line 335 of file Parameters.h.

◆ getBOnAScalar()

float Parameters::getBOnAScalar ( ) const

inline

Returns: Nonlinear coefficient.

Definition at line 366 of file Parameters.h.

◆ getBOnAScalarFlag()

bool Parameters::getBOnAScalarFlag ( ) const

inline

Returns: True if scalar

Definition at line 361 of file Parameters.h.

◆ getC0Scalar()

float Parameters::getC0Scalar ( ) const

inline

Returns: Sound speed.

Definition at line 254 of file Parameters.h.

◆ getC0ScalarFlag()

bool Parameters::getC0ScalarFlag ( ) const

inline

Returns: True if scalar.

Definition at line 249 of file Parameters.h.

◆ getC2Scalar()

float Parameters::getC2Scalar ( ) const

inline

Returns: Sound speed.

Definition at line 259 of file Parameters.h.

◆ getCheckpointFile()

Hdf5File& Parameters::getCheckpointFile ( )

inline

Returns: Handle to the checkpoint file.

Definition at line 163 of file Parameters.h.

◆ getCheckpointFileName()

std::string Parameters::getCheckpointFileName ( ) const

inline

Returns: Checkpoint file name

Definition at line 184 of file Parameters.h.

◆ getCheckpointInterval()

size_t Parameters::getCheckpointInterval ( ) const

inline

Returns: Checkpoint interval in seconds.

Definition at line 145 of file Parameters.h.

◆ getCompressionLevel()

size_t Parameters::getCompressionLevel ( ) const

inline

Returns: Compression level value for output and checkpoint files.

Definition at line 127 of file Parameters.h.

◆ getCopySensorMaskFlag()

bool Parameters::getCopySensorMaskFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 586 of file Parameters.h.

◆ getCRef()

float Parameters::getCRef ( ) const

inline

Returns: Reference sound speed.

Definition at line 244 of file Parameters.h.

◆ getDt()

float Parameters::getDt ( ) const

inline

Returns: dt value.

Definition at line 222 of file Parameters.h.

◆ getDtRho0SgxScalar()

float Parameters::getDtRho0SgxScalar ( ) const

inline

Returns: Staggered density.

Definition at line 281 of file Parameters.h.

◆ getDtRho0SgyScalar()

float Parameters::getDtRho0SgyScalar ( ) const

inline

Returns: Staggered density.

Definition at line 291 of file Parameters.h.

◆ getDtRho0SgzScalar()

float Parameters::getDtRho0SgzScalar ( ) const

inline

Returns: Staggered density.

Definition at line 301 of file Parameters.h.

◆ getDx()

float Parameters::getDx ( ) const

inline

Returns: dx value.

Definition at line 227 of file Parameters.h.

◆ getDy()

float Parameters::getDy ( ) const

inline

Returns: dy value.

Definition at line 232 of file Parameters.h.

◆ getDz()

float Parameters::getDz ( ) const

inline

Returns: dz value

Definition at line 237 of file Parameters.h.

◆ getFileHeader()

Hdf5FileHeader& Parameters::getFileHeader ( )

inline

Returns: Handle to the file header.

Definition at line 168 of file Parameters.h.

◆ getFullDimensionSizes()

DimensionSizes Parameters::getFullDimensionSizes ( ) const

inline

Returns: Dimension sizes of 3D real matrices.

Definition at line 191 of file Parameters.h.

◆ getGitHash()

string Parameters::getGitHash ( ) const

Returns: Git hash compiled in using -D parameter.

Get GitHash of the code

Definition at line 471 of file Parameters.cpp.

◆ getInitialPressureSourceFlag()

size_t Parameters::getInitialPressureSourceFlag ( ) const

inline

Returns: 0 if the source is disabled, 1 otherwise.

Definition at line 413 of file Parameters.h.

◆ getInputFile()

Hdf5File& Parameters::getInputFile ( )

inline

Returns: Handle to the input file.

Definition at line 153 of file Parameters.h.

◆ getInputFileName()

std::string Parameters::getInputFileName ( ) const

inline

Returns: Input file name

Definition at line 174 of file Parameters.h.

◆ getInstance()

Parameters & Parameters::getInstance ( )

static

Returns: The only instance of the class.

Get instance of singleton class.

Definition at line 84 of file Parameters.cpp.

◆ getNonLinearFlag()

size_t Parameters::getNonLinearFlag ( ) const

inline

Returns: 0 if the simulation is linear, 1 otherwise.

Definition at line 319 of file Parameters.h.

◆ getNonUniformGridFlag()

size_t Parameters::getNonUniformGridFlag ( ) const

inline

Returns: Non uniform flag.

Definition at line 309 of file Parameters.h.

◆ getNt()

size_t Parameters::getNt ( ) const

inline

Returns: Total number of time steps.

Definition at line 203 of file Parameters.h.

◆ getNumberOfThreads()

size_t Parameters::getNumberOfThreads ( ) const

inline

Returns: Number of CPU threads to use.

Definition at line 121 of file Parameters.h.

◆ getOutputFile()

Hdf5File& Parameters::getOutputFile ( )

inline

Returns: Handle to the output file.

Definition at line 158 of file Parameters.h.

◆ getOutputFileName()

std::string Parameters::getOutputFileName ( ) const

inline

Returns: Output file name.

Definition at line 179 of file Parameters.h.

◆ getPmlXAlpha()

float Parameters::getPmlXAlpha ( ) const

inline

Returns: Attenuation for PML in x.

Definition at line 389 of file Parameters.h.

◆ getPmlXSize()

size_t Parameters::getPmlXSize ( ) const

inline

Returns: PML size in x.

Definition at line 373 of file Parameters.h.

◆ getPmlYAlpha()

float Parameters::getPmlYAlpha ( ) const

inline

Returns: Attenuation for PML in y.

Definition at line 394 of file Parameters.h.

◆ getPmlYSize()

size_t Parameters::getPmlYSize ( ) const

inline

Returns: PML size in y.

Definition at line 378 of file Parameters.h.

◆ getPmlZAlpha()

float Parameters::getPmlZAlpha ( ) const

inline

Returns: Attenuation for PML in z.

Definition at line 399 of file Parameters.h.

◆ getPmlZSize()

size_t Parameters::getPmlZSize ( ) const

inline

Returns: PML size in z.

Definition at line 383 of file Parameters.h.

◆ getPressureSourceFlag()

size_t Parameters::getPressureSourceFlag ( ) const

inline

Returns: 0 if the source is disabled.; Length of the input signal in time steps.

Definition at line 408 of file Parameters.h.

◆ getPressureSourceIndexSize()

size_t Parameters::getPressureSourceIndexSize ( ) const

inline

Returns: Size of the pressure source in grid points.

Definition at line 444 of file Parameters.h.

◆ getPressureSourceMany()

size_t Parameters::getPressureSourceMany ( ) const

inline

Returns: Number of time series in the pressure source.

Definition at line 466 of file Parameters.h.

◆ getPressureSourceMode()

size_t Parameters::getPressureSourceMode ( ) const

inline

Returns: Pressure source mode (Dirichlet or additive).

Definition at line 461 of file Parameters.h.

◆ getProgressPrintInterval()

size_t Parameters::getProgressPrintInterval ( ) const

inline

Returns: How often to print progress.

Definition at line 133 of file Parameters.h.

◆ getReducedDimensionSizes()

DimensionSizes Parameters::getReducedDimensionSizes ( ) const

inline

Returns: Dimension sizes of reduced complex 3D matrices.

Definition at line 197 of file Parameters.h.

◆ getRho0Scalar()

float Parameters::getRho0Scalar ( ) const

inline

Returns: Density.

Definition at line 271 of file Parameters.h.

◆ getRho0ScalarFlag()

bool Parameters::getRho0ScalarFlag ( ) const

inline

Returns: True if scalar.

Definition at line 266 of file Parameters.h.

◆ getRho0SgxScalar()

float Parameters::getRho0SgxScalar ( ) const

inline

Returns: Staggered density.

Definition at line 276 of file Parameters.h.

◆ getRho0SgyScalar()

float Parameters::getRho0SgyScalar ( ) const

inline

Returns: Staggered density.

Definition at line 286 of file Parameters.h.

◆ getRho0SgzScalar()

float Parameters::getRho0SgzScalar ( ) const

inline

Returns: Staggered density.

Definition at line 296 of file Parameters.h.

◆ getSamplingStartTimeIndex()

size_t Parameters::getSamplingStartTimeIndex ( ) const

inline

Returns: When to start sampling data.

Definition at line 499 of file Parameters.h.

◆ getSensorMaskCornersSize()

size_t Parameters::getSensorMaskCornersSize ( ) const

inline

Returns: Number of cuboids.

Definition at line 494 of file Parameters.h.

◆ getSensorMaskIndexSize()

size_t Parameters::getSensorMaskIndexSize ( ) const

inline

Returns: Number of grid points.

Definition at line 489 of file Parameters.h.

◆ getSensorMaskType()

SensorMaskType Parameters::getSensorMaskType ( ) const

inline

Returns: Sensor mask type.

Definition at line 484 of file Parameters.h.

◆ getStorePressureFinalAllFlag()

bool Parameters::getStorePressureFinalAllFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 535 of file Parameters.h.

◆ getStorePressureMaxAllFlag()

bool Parameters::getStorePressureMaxAllFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 525 of file Parameters.h.

◆ getStorePressureMaxFlag()

bool Parameters::getStorePressureMaxFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 515 of file Parameters.h.

◆ getStorePressureMinAllFlag()

bool Parameters::getStorePressureMinAllFlag ( ) const

inline

Returns: true if the flag is set.

Definition at line 530 of file Parameters.h.

◆ getStorePressureMinFlag()

bool Parameters::getStorePressureMinFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 520 of file Parameters.h.

◆ getStorePressureRawFlag()

bool Parameters::getStorePressureRawFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 505 of file Parameters.h.

◆ getStorePressureRmsFlag()

bool Parameters::getStorePressureRmsFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 510 of file Parameters.h.

◆ getStoreVelocityFinalAllFlag()

bool Parameters::getStoreVelocityFinalAllFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 580 of file Parameters.h.

◆ getStoreVelocityMaxAllFlag()

bool Parameters::getStoreVelocityMaxAllFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 570 of file Parameters.h.

◆ getStoreVelocityMaxFlag()

bool Parameters::getStoreVelocityMaxFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 560 of file Parameters.h.

◆ getStoreVelocityMinAllFlag()

bool Parameters::getStoreVelocityMinAllFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 575 of file Parameters.h.

◆ getStoreVelocityMinFlag()

bool Parameters::getStoreVelocityMinFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 565 of file Parameters.h.

◆ getStoreVelocityNonStaggeredRawFlag()

bool Parameters::getStoreVelocityNonStaggeredRawFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 547 of file Parameters.h.

◆ getStoreVelocityRawFlag()

bool Parameters::getStoreVelocityRawFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 542 of file Parameters.h.

◆ getStoreVelocityRmsFlag()

bool Parameters::getStoreVelocityRmsFlag ( ) const

inline

Returns: True if the flag is set.

Definition at line 555 of file Parameters.h.

◆ getTimeIndex()

size_t Parameters::getTimeIndex ( ) const

inline

Returns: Actual time step.

Definition at line 208 of file Parameters.h.

◆ getTransducerSourceFlag()

size_t Parameters::getTransducerSourceFlag ( ) const

inline

Returns: 0 if the transducer is disabled.; Length of the input signal in time steps.

Definition at line 419 of file Parameters.h.

◆ getTransducerSourceInputSize()

size_t Parameters::getTransducerSourceInputSize ( ) const

inline

Returns: Size of the transducer source in grid points.

Definition at line 449 of file Parameters.h.

◆ getVelocitySourceIndexSize()

size_t Parameters::getVelocitySourceIndexSize ( ) const

inline

Returns: Size of the velocity source in grid points.

Definition at line 454 of file Parameters.h.

◆ getVelocitySourceMany()

size_t Parameters::getVelocitySourceMany ( ) const

inline

Returns: Number of time series in the velocity sources.

Definition at line 477 of file Parameters.h.

◆ getVelocitySourceMode()

size_t Parameters::getVelocitySourceMode ( ) const

inline

Returns: Pressure source mode (Dirichlet or additive).

Definition at line 472 of file Parameters.h.

◆ getVelocityXSourceFlag()

size_t Parameters::getVelocityXSourceFlag ( ) const

inline

Returns: 0 if the source is disabled.; Length of the input signal in time steps.

Definition at line 425 of file Parameters.h.

◆ getVelocityYSourceFlag()

size_t Parameters::getVelocityYSourceFlag ( ) const

inline

Returns: 0 if the source is disabled.; Length of the input signal in time steps.

Definition at line 431 of file Parameters.h.

◆ getVelocityZSourceFlag()

size_t Parameters::getVelocityZSourceFlag ( ) const

inline

Returns: 0 if the source is disabled.; Length of the input signal in time steps.

Definition at line 437 of file Parameters.h.

◆ init()

void Parameters::init	(	int	argc,
		char **	argv
	)

Parameters

[in]	argc	- Number of commandline parameters.
[in]	argv	- Commandline parameters.

Exceptions

std::invalid_argument - If sampling is supposed to start out of the simulation time span.

Parse command line and read scalar values from the input file to initialise the class and the simulation.

Definition at line 102 of file Parameters.cpp.

◆ isCheckpointEnabled()

bool Parameters::isCheckpointEnabled ( ) const

inline

Returns: true if checkpointing is enabled.

Definition at line 140 of file Parameters.h.

◆ isPrintVersionOnly()

bool Parameters::isPrintVersionOnly ( ) const

inline

Returns: True if the flag is set.

Definition at line 95 of file Parameters.h.

◆ printSimulatoinSetup()

void Parameters::printSimulatoinSetup ( )

Print parameters of the simulation based in the actual level of verbosity.

Definition at line 137 of file Parameters.cpp.

◆ readScalarsFromInputFile()

void Parameters::readScalarsFromInputFile ( )

Exceptions

ios:failure	- If the file cannot be open or is of a wrong type or version.
std::invalid_argument	- If some values are not correct or not supported.

Warning: The file is opened in this routine and left open for further use.

Read scalar values from the input HDF5 file.

Definition at line 169 of file Parameters.cpp.

◆ saveScalarsToOutputFile()

void Parameters::saveScalarsToOutputFile ( )

Exceptions

ios:failure - If the output file is closed.

Warning: The file is expected to be open.

Save scalars into the output HDF5 file.

Definition at line 391 of file Parameters.cpp.

◆ setAbsorbEtaScalar()

void Parameters::setAbsorbEtaScalar ( const float absrobEta )

inline

Parameters

[in] absrobEta - New value for absorb eta

Definition at line 345 of file Parameters.h.

◆ setAbsorbTauScalar()

void Parameters::setAbsorbTauScalar ( const float absorbTau )

inline

Parameters

[in] absorbTau - New value for absorb tau.

Definition at line 355 of file Parameters.h.

◆ setTimeIndex()

void Parameters::setTimeIndex ( const size_t timeIndex )

inline

Parameters

[in] timeIndex - Actual time step.

Definition at line 213 of file Parameters.h.

The documentation for this class was generated from the following files:

Parameters/Parameters.h
Parameters/Parameters.cpp

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Private Attributes

Static Private Attributes

Detailed Description

Member Enumeration Documentation

◆ SensorMaskType

Constructor & Destructor Documentation

◆ ~Parameters()

◆ Parameters()

Member Function Documentation

◆ getAbsorbEtaScalar()

◆ getAbsorbingFlag()

◆ getAbsorbTauScalar()

◆ getAlphaCoeffScalar()

◆ getAlphaCoeffScalarFlag()

◆ getAlphaPower()

◆ getBOnAScalar()

◆ getBOnAScalarFlag()

◆ getC0Scalar()

◆ getC0ScalarFlag()

◆ getC2Scalar()

◆ getCheckpointFile()

◆ getCheckpointFileName()

◆ getCheckpointInterval()

◆ getCompressionLevel()

◆ getCopySensorMaskFlag()

◆ getCRef()

◆ getDt()

◆ getDtRho0SgxScalar()

◆ getDtRho0SgyScalar()

◆ getDtRho0SgzScalar()

◆ getDx()

◆ getDy()

◆ getDz()

◆ getFileHeader()

◆ getFullDimensionSizes()

◆ getGitHash()

◆ getInitialPressureSourceFlag()

◆ getInputFile()

◆ getInputFileName()

◆ getInstance()

◆ getNonLinearFlag()

◆ getNonUniformGridFlag()

◆ getNt()

◆ getNumberOfThreads()

◆ getOutputFile()

◆ getOutputFileName()

◆ getPmlXAlpha()

◆ getPmlXSize()

◆ getPmlYAlpha()

◆ getPmlYSize()

◆ getPmlZAlpha()

◆ getPmlZSize()

◆ getPressureSourceFlag()

◆ getPressureSourceIndexSize()

◆ getPressureSourceMany()

◆ getPressureSourceMode()

◆ getProgressPrintInterval()

◆ getReducedDimensionSizes()

◆ getRho0Scalar()

◆ getRho0ScalarFlag()

◆ getRho0SgxScalar()

◆ getRho0SgyScalar()

◆ getRho0SgzScalar()

◆ getSamplingStartTimeIndex()

◆ getSensorMaskCornersSize()

◆ getSensorMaskIndexSize()

◆ getSensorMaskType()

◆ getStorePressureFinalAllFlag()

◆ getStorePressureMaxAllFlag()

◆ getStorePressureMaxFlag()

◆ getStorePressureMinAllFlag()

◆ getStorePressureMinFlag()

◆ getStorePressureRawFlag()

◆ getStorePressureRmsFlag()

◆ getStoreVelocityFinalAllFlag()

◆ getStoreVelocityMaxAllFlag()
